Host Ports

Two 3Gb/s SAS ports

Drive Connectivity

• 3Gb/s SAS connectivity

• Accommodates 3.5-inch disk drives

• Dedicated bandwidth to each connected drive

Supported Drives

Please refer to corresponding RAID systems

Maximum Number of Drives

Per system: 12

Corresponding RAID

Please refer to Related Information

Form Factor

2U

Green Design

• High-efficiency power supplies

• Intelligent multi-level drive spin-down

Availability and Reliability

• Redundant, hot-swappable hardware modules

• Multi-pathing support (EonPath)

• Device mapper support

Notification

Various event notification methods including email, LAN broadcast, fax, SNMP traps, SMS, and Skype.

Service and Support

All EonStor DS systems are shipped with 3-year Standard Service

• Standard service:
  - Hardware warranty
  - Software update; 8x5 phone, web and email support

• Upgrade/Extension service*:
  Replacement part dispatch on the next business day (up to 5 years)
  - Advanced Service: 24x7 phone, web and email support + onsite diagnostics on the next business day
  - Premium Service: 24x7 phone, web and email support + onsite diagnostics in 4 hours

* Optional
** Service may vary by region

Power

• Power supplies: Two 460W DC

• AC voltage: 100VAC @ 8A to 240VAC @ 4A with PFC (auto-switching)

• Frequency: 50-60 Hz

Environmental

• Temperature:0 to 40C operating/ -40 to 60C non-operating

• Altitude: Sea level to 3660m (12,000ft) operating / sea level to 12,192m (40,000ft) non-operating

• Relative humidity: 5 to 95% non-condensing, operating and non-operating

Dimensions

Without chassis ears / protrusions:
446mm (W) x 88mm (H) x 498mm (D)

Weight

Without HDDs:17.60kg (38.80lbs)

Package Dimensions

780mm (W) x 390mm (H) x 570mm (D)
