GIGABIT PERFORMANCE
The unmanaged switch offers Gigabit speeds to minimize transfer times and greatly enhance the ability to stream high-bandwidth files to connected devices without interference.
POWER WHERE YOU NEED IT
With PoE+ built-in, networking devices such as network hubs, IP phones, and IP cameras can be located anywhere without the need for AC outlets.
PLUG AND PLAY CONVENIENCE
The Linksys unmanaged switch offers a quick and easy solution to extend your office network with plug & play installation.
QUALITY OF SERVICE (QOS) TRAFFIC PRIORITIZATION
QoS traffic prioritization provides the ability to give precedence to particular devices or activities to ensure mission critical data throughput is maintained regardless of network congestion. Auto-sensing ports automatically optimize speed for each connected device.
Specifications:
| Model: |
LGS124P |
| Standards: |
IEEE 802.3, 802.3u, 802.3x, 802.3ab, 802.3az, 802.3af, and 802.3at (PoE+) |
| Number of Ports: |
24-ports switch with 12 PoE+ ports (ports 16 and 1318) and dedicated PoE power budget of 120 W |
| Bandwidth: |
48 Gbps (non-blocking) |
| Performance: |
Full line rate and forwarding rate of 64B frame at: 1.488 Mpps for 1000M port, 0.1488 Mpps for 100M port, 0.01488 Mpps for 10M port |
| Quality of Service: |
802.1p and DSCP |
| Status LEDs: |
Link, speed, activity, and PoE indicators |
| Power Supply: |
Internal |
| Power: |
100240 VAC, 50/60 Hz |
| Power Saving: |
Cable connected detection Sleep mode |
| Power Consumption n Idle/Use (100% Traffic) |
7.79 W / 17.65 W |
| Fan |
One |
| Unit Dimensions |
440 x 200 x 44 mm (171.6 x 78 x 17.16 in.) |
| Unit Weight |
2.758 kg (6.08 lbs) |
| Temperature (Operating) |
050C (32122F) |
| Temperature (Storing) |
-4070C (-40158F) |
| Humidity (Operating) |
1090% (non-condensing) |
| Humidity (Storing) |
1090% (non-condensing) |
| Certifications |
FCC Class A, CE, UL, CB |
| Mounting |
Rack mount |
| Minimum System Requirements |
Connected devices need Ethernet connectivity and Ethernet cables |
| Warranty and Support |
Lifetime limited warranty |
| Package Contents |
Linksys LGS124P 24-Port Gigabit Ethernet PoE Switch, Power Cord, Quick Start Guide |
| MAC Address Table |
8K |
