Wireless AC Speed up to 1200Mbps
Linksys Business Wireless-AC Access Points deliver next generation Wi-Fi 802.11ac technology, at data rates up to 3x faster than 802.11n.* With a data link rate of up to 1200 Mbps, your laptop and other wireless devices can experience the fastest possible performance.
2-in-1 Workgroup Bridge & Access Point
Supports deployment as a traditional access point or set up as a workgroup bridge to extend wireless range.
Easy to Use with PoE+
Integrated with 802.3at Power over Ethernet Plus (PoE+) capability to eliminate external adapters and facilitate optimal placement.
Comprehensive Network Security
Protect and secure your wireless network with business-class security features including Wi-Fi Protected Access (WPA/WPA2), 802.1X Supplicant, MAC-based ACL, Rogue AP Detection, SSID-to-VLAN Mapping, and more.
Specifications:
Hardware Specs
| Model: |
LAPAC1200 |
| Standards: |
IEEE 802.11a, 802.11b, 802.11g, 802.11n, 802.11ac, 802.3, 802.3u, and 802.3at |
| Frequency: |
2.4 GHz and 5 GHz (concurrent) |
| MIMO: |
2 x 2 |
| Antenna: |
Internal Antenna |
| RF Output Power: |
High Power PA |
| PoE: |
802.3at |
| Installation Options: |
Ceiling Mount, Wall Mount or Desktop |
| Ethernet Port: |
1, Gigabit Ethernet Port |
| Security Lock: |
Kensington lock slot |
| LED: |
One system LED |
| AC Power Adapter: |
12V/1.5A |
| Hardware Reset Button: |
Yes |
Frequency Band and
Operating Channels: |
2.412 to 2.462 GHz; 11 channels
5.180 to 5.240 GHz; 4 channels
5.745 to 5.825 GHz; 5 channels |
| Antenna Gain dBi: |
TBD |
| Transmitted Power: |
TBD |
| Receiver Sensitivity: |
TBD |
| Physical Dimension (L x W x H): |
243.08 x 236.98 x 43.69 mm |
| Weight: |
TBD |
| Maximum Power Consumption: |
TBD |
| Compliance Class: |
B, Wireless |
| Operating Temperature: |
0 to 40 C (32 to 104F) |
| Storage Temperature: |
-20 to 70C (-4 to 158F) |
| Operating Humidity: |
10% to 85% (non-condensing) |
| Storage Humidity: |
10% to 90% (non-condensing) |
| Regulatory Certification: |
FCC, CE, IC |
| Warranty Period: |
Limited Lifetime |
Software Specs
| Multiple SSIDs: |
16 |
| VLAN Support: |
Yes |
| Number of VLANs: |
17 |
| SSID to VLAN Mapping: |
Yes |
| Workgroup Bridge: |
Yes |
| IPv6: |
Yes |
| WEP, WPA, WPA2, 802.1X with RADIUS: |
Yes, Enterprise authentication is included |
| Access Control: |
Yes, MAC based ACL with local or remote RADIUS server authentication |
| Rogue AP Detection: |
Yes |
| 802.1X Supplicant: |
Yes |
| Channel Isolation: |
Yes |
| WMM: |
Yes |
| Rate Limit: |
Yes, Bandwidth Management per SSID |
| Scheduler: |
Yes, Time-based profiles per SSID |
| Band Steering: |
Yes |
| Management Interface: |
Web Browser, SNMP |
| Event Notification : |
Local Log, Remote Syslog, and Email Alert |
| Network Diagnostics: |
Log, Ping, Packet Capture |
