- IntelCeleron J1900 Quad-Core SoC processor/4GB DDR3 RAM
- Built-in Mini-UPS, Contingency Power Supply
- Disk Clone and Wipe, 100% Data Wipe, Rock-Solid Security
- Link Aggregation, 5 LAN for Network Performance Improvement
- VPN server, Secure Remote Access
- Snapshot Backup, Easy Recovery with Snapshots
- Real-time Remote Replication
- iSCSI LUN and Thin-Provisioning supported
- VMware, Citrix, Microsoft Hyper-V Compliance
Features
Snapshot Backup
With BTRFS support, Thecus NAS users can enjoy the simplicity of snapshot backups. Through BTRFS subvolumes, snapshots of data at various time points can be manually or automatically made and just as easily later restored to rollback files or folders to previous states.
Mini-UPS
With the A built-in Mini-UPS, not even a power outage can slow you down. The Mini-UPS provides power to allow the N5810PRO to write unwritten data to the hard disks and safely shutdown, ensuring the integrity of your data and preserving your memories.
Disk Clone and Wipe
Disk Clone allows users to copy the entire contents of a disk to one or many other disks while Disk Wipe allows for permanent volume data destruction.
VPN Server
A VPN Server allows users to remotely access a secure network. with VPNs, businesses will be able to utilize a cost-effective, scalable and secured network infrastructure for its client base.
Data Guard
Data Guard backup solution is the ultimate software as it provides both local and remote parts. Currently, data is backed up across RAID volumes, external USB drives, and eSATA. In addition, Data Guard uses innovative technology to sync data across the network to other NAS and servers. More importantly, Thecus® Data Guard is the total backup solution which makes managing NAS user-friendly and convenient.
Data Burn
NAS data can now be burned directly to CD, DVD, and Blu-ray discs with Data Burn, this hassle-free module makes burning data to a disk effortless. In addition, burning ISO image file is also supported. Whether you’re managing audio, media or essential files; Data Burn copies information fast while significantly reducing waiting time. The process of burning file to disk is now easy and smooth with Data Burn module.
Link Aggregation
5 LAN for Network Performance Improvement.Link aggregation can sustain multiple network connections and provide redundancy in case one of the links fails. Thecus NAS supports 7 modes which provide Load Balance, Failover, 802.3ad, Balance-XOR, Balance-TLB, and Balance-ALB, Broadcast.
Antivirus
Thecus’ innovative hardware helps prevent failures. But sometimes you have to protect the NAS against itself. Adding an antivirus to the already comprehensive software bundle will provide the necessary software protection by scanning the files on your NAS and defending it against possible threats. McAfee is the world’s largest dedicated security technology company and shares Thecus’ spirit of dedication and quality. By establishing a strong partnership with them, Thecus will allow users the benefit of McAfee’s powerful software on their NAS entirely for free.
Cloud Backup
The private and public clouds meet with Thecus’ new DropBox, Amazon S3 and ElephantDrive cloud backup functionality! Guard your data with RAID at home and an additional level of protection in the Cloud. Just drag and drop files into the folder on your NAS and access them on any computer or mobile device with DropBox, Amazon S3 or ElephantDrive.
HDMI Output
Make your NAS into the ultimate multimedia hub! The N5810PRO’s HDMI output allows you to connect your NAS directly to your TV for device management, web browsing with Flash support, and even HD video playback. Don’t force yourself to watch movies on that tiny little computer screen anymore, take it to the living room!
USB 3.0 Connectivity
The next generation of connectivity is here with speeds 10x faster than USB 2.0. Whether connecting digital cameras and smart phones, backing up large external hard drives, or extending the capacity of your NAS, USB 3.0 will make sure it's done in no time at up to 5 Gbit/s. Backwards compatibility adds the connectivity of a world full of USB 2.0 and USB 1.1 devices to get the best combination of speed and universal access.
Acronis True Image
Thecus brings the best to the table with Acronis’s advanced backup software. Back up all your data with One-click Protection or pick and choose only your most important files. Acronis sports a slick interface, user-friendly design, and comprehensive features to keep your data safe.
Multiple RAID
When it comes to data management, Thecus NAS truly let you have it your way. Create multiple RAID volumes each supporting different RAID modes including RAID 0, 1, 5, 6, 10 and JBOD for your own balance of performance and data protection. Should a hard drive malfunction occur, changing one is simple thanks to online RAID migration and expansion, hot spare, and auto rebuild.
Multiple File Systems
Support for multiple file systems including EXT3, EXT4, Btrfs and XFS, gives Thecus NAS flexibility to handle many different types of environments. Users can simultaneously use different file systems across multiple RAID volumes to get the best of each one.
iSCSI Thin-Provisioning
Get the most out of your storage space with the extreme speed of iSCSI and the efficiency of iSCSI thin provisioning. Connect through iSCSI for the fastest data transfer speeds available and make wasted disk space a thing of the past with thin provisioning's flexible storage functionality.
iOS/Android Connectivity
In the modern world, nothing is as important as reaching your data from anywhere. With T-OnTheGo and the T-Dashboard, you can manage your NAS, and upload to and download/stream from your NAS using an iOS or Android device on the go.
Rsync
Backing up your data is very necessary, and everyone has specific needs when it comes to storage. Thecus’s Rsync functionality gives users great flexibility with remote backup capability, a flexible scheduler, and the stability of Linux-based transfer.
User Quotas
Divide the massive storage of a Thecus NAS among multiple users. Whether there are two users or 100, user quotas make it easy to divvy up and manage disk space.
Overview
Thecus today announced its new zero-crash 5-bay NAS, the N5810PRO. Embedded with an Intel Celeron processor J1900 Quad Core 2.0 GHz SoC and Mini-UPS battery, the Thecus N5810PRO empowers users with lightning fast performance while providing impenetrable data integrity.
In todays ever-evolving digital environment, businesses require robust storage solutions that provide premium performance with piece of mind that their data will always be secure, said Florence Shih, CEO of Thecus Technology. The N5810PRO is designed to equip users with a comprehensive set of applications that will optimize their business environment while addressing the needs for performance and security.
Powered by the Intel Celeron processor, 4 GB DDR3 RAM (expandable to 8GB), and equipped with 5 Gigabit LAN ports, the N5810PRO reaches blazing throughput speeds of up to 500 MB/s. The N5810PRO supports seven modes of link aggregation including fault tolerance for resilience and port-trunking modes for increased performance. Built to grow with your business, total storage can be expanded to 40TB, while support for VMware , Citrix , and Microsoft Hyper-V allow for seamless integration into a businesses virtualization environment.
The integration of the Intel Celeron processor J1900 Quad Core 2.0 GHz SoC with the Thecus N5810PRO enables users to simultaneously utilize the many features of the NAS while maintaining a high-performance environment, said Bev Crair, Vice President, Data Center Group and General Manager, Storage Group, Intel Corporation. The N5810PRO is another example of successful collaborative products from Intel and Thecus.
In order to protect your data in the occurrence of a sudden power outage, the N5810PRO is outfitted with a lithium-ion mini-UPS, allowing the system to store unwritten data to the hard disks and safely shut down. The new 5-bay NAS also supports an array of backup features including Data Guard for local and remote backups, Data Burn, and Snapshot Backup using the Btrfs file system. Users can now enjoy enhanced storage functionality while simplifying storage management.
The N5810PRO runs on the intuitive, easy-to-use Thecus OS5 operating system. The re-tooled software includes VPN Server for secure remote access and Disk Clone and Wipe for convenient data management. Users will also be able to enjoy a comprehensive set of entertainment features facilitated by HDMI output and Kodi for multimedia playback and mobile access with the powerful Thecus mobile app, T-OnTheGo.
Specs
1. Hardware Platform
| Item |
Spec |
| Processor |
Intel Celeron J1900 Quad-Core SoC |
| System Memory |
4 GB DDR3 |
| LAN Interface |
RJ-45x5 : 10/100/1000 BASE-TX Auto MDI/MDI-X
WOL supported (eth0) |
| USB Interface |
USB 3.0 host port (Front x1,Back x2)
USB 2.0 host port (Back x2)
|
| LCM Module |
LCM display
4 buttons (ENTER, ESC, UP, DOWN)
|
| HDMI Output |
HDMI port (back x1) |
| Line Out |
Supported |
| Disk Interface |
5 x SATA for internal |
| Power Supply |
130W Internal Power Supply |
| Thermal/Fan control |
Thermal sensor on processor temperature
System FAN speed controlled by temperature |
| System Clock |
Battery-backed up system clock |
| Power Management |
Auto power on after shutdown due to power loss |
| Buzzer |
Adjustable frequency alarm |
| Buttons |
Power button
LCM button |
| Environment |
Temperature: 0C to 40C Operation
-40C to 70C Non-operation
Humidity: 0 ~ 80 % R.H. (Non-condensing)
|
| Chassis |
Tower Metal Chassis |
| Lithium-ion Battery |
Built-in battery backup module (Mini-UPS) |
| Dimensions (HxWxD) |
230 x 190 x 240 (mm)/ 9.06 x7.48 x 9.45 (in) |
| Weight |
5.46(Kgs) |
| Certificates |
CE/FCC/C-Tick/VCCI/BSMI
RoHS
WEEE |
2. Software Functions
| RAID |
| RAID Modes |
RAID 0, 1, 5, 6, 10 and JBOD |
| Auto-rebuild |
Supported |
| Hot-swap |
Supported |
| Hot Spare |
Supported |
| Online RAID Migration |
Supported |
| Online RAID Expansion |
Supported |
| RAID Volume Encryption |
AES256bit |
| Disk |
| Power Management |
Available spin-down on idle setting |
| Bad Block Scanning |
Supported |
| SMART Info |
Supported |
| SMART Test |
Supported |
| Disk Roaming |
Supports volume-based roaming to other Thecus NAS.(OS5 64bit) |
| Network |
| Configuration |
Fixed IP address, dynamic IP address |
| Transport Protocols |
TCP/IP/AppleTalk |
| File Protocols |
SMB/CIFS, HTTP/HTTPS, FTP, NFS v4, AFP |
| Link Aggregation |
Load balance, Failover, 802.3ad, Balance-XOR, Balance-TLB, Balance-ALB, Broadcast |
| TCP/IP |
IPV6 & IPV4 |
| DDNS |
Supported |
| SSH |
Supported |
| UPnP |
Supported |
| UPnP Port forwarding |
Supported |
| Bonjour |
Supported |
| VPN Server |
Supported |
| vLan |
Supported |
| System status |
| System Monitor |
Monitoring CPU, memory, temperature, fan, network utilization and protocols access user count |
| Syslog Management |
Send syslog to assigned location
Act as syslog server to receive log info from other systems |
| Data Access |
| Client OS Support |
Windows XP and after
Windows Server 2003 and after
UNIX/Linux
Mac OS X |
| FTP |
Built-in FTP server with bandwidth control |
| Secure FTP |
Built-in secure FTP server with bandwidth control |
| TFTP |
Users can download and upload files with TFTP programs |
| Download Manager |
BT download (via Transmission module)
NZB download (via NZB module) |
| WebDAV/WebDAV SSL |
Supported |
| Printer Server (IPP) |
Supports USB printers
Supports a wide range of IPP printers
Client can manage print tasks (list/delete) via web user interface |
| Data Backup |
| Client Incremental Data Backup |
Acronis True Image (OEM version) |
| Client System Disaster Recovery |
Acronis True Image (OEM version) |
| Data Burn |
Create files to ISO image and burn to optical disc
Create files to ISO image
Read ISO image from optical disc and write to NAS |
| Mac OS X Time Machine |
Supported |
| Data Guard |
Remote Backup/Local Backup |
| Snapshot |
Supported(Btrfs) |
| Block Level Access |
| iSCSI Target/Initiator |
Supports Microsoft/Mac OS X/Linux initiators and Thecus NAS targets |
| iSCSI Thin Provisioning |
Supported |
| iSCSI VAAI |
Supported |
| MPIO(Five GbE Ports) |
Supported |
| MCS(Five GbE Ports) |
Supported |
| Clustering |
Supported |
| SCSI3 Persistent Group Reservation |
Supported |
| Power Management |
| Scheduled Power On/Off |
Supported |
| Volume Management |
| Multiple RAID |
Supported |
| Multiple File System Selectable |
EXT3/EXT4/XFS/Btrfs |
| Multimedia Support |
| iTunes Server |
Supports AAC, MP3 w/ID3 tag and WAV |
| Piczza! Photo Server (via module) |
Supports GIF, JPG (JPEG), BMP and PNG
Supports EXIF display
Supports slide shows |
| Media Server |
Supports uPnP AV streaming protocol(via Module) |
| User Authentication |
| Local User |
Supports built-in user accounts |
| Local Group |
Supports built-in user groups |
| Windows ADS |
Supported |
| LDAP |
Supported |
| Access Guard |
Supports Black & White list/IP Filter |
| Cloud Backup |
| DropBox |
Supported (via module) |
| ElephantDriver |
Supported (via module) |
| Amazon S3 |
Supported |
| File System |
| Type |
Journaling File System |
| Language Support |
Unicode Support |
| Authorization (ACL) |
Read, write, or deny privileges to individual users or groups in folders and sub-folders |
| User Quota |
Supported |
| Administration |
| User Interface |
Web-based user interface supports English, Traditional Chinese, Simplified Chinese, Japanese, Korean, French, German, Italian, Spanish, Russian, Polish, Portuguese, Turkish and Czech. |
| Utility Program |
Supports Windows 8/7/Vista/2003/XP/2000 |
| Email Notifications |
Sends system messages via email to the system administrator |
| Thecus ID/DDNS |
Support One free DDNS registration (e.g. xxx.thecuslink.com) |
| SNMP Trap |
System information trap out |
| Mobile Applications (iOS/Android) |
| T- Dashboard |
Mobile monitoring and administration (via module) |
| T-OnTheGo |
Upload, download and stream multimedia |
| Data Security |
| Virus Scan |
Supports McAfee (via module) |
| Capacity Expansion |
| Stackable |
Can extend for 5 additional iSCSI volumes from other Thecus NAS |
| Others |
| Recycle Bin |
Supported |
| Web Disk |
Supported (via module) |
| Web Server |
Supported (via module) |
| ISO Mount |
Supported |
| User / System Module |
Supported |
| IP Cam Surveillance |
Supports up to 5 IP cameras (via module) |
| Auto Module Installation |
Thecus module server automatically provides the latest modules and updates through the user interface. |
| Local Display |
X-Window via HDMI output |
