All stock codes associated to this product
JG811AAE
HP VSR1001 Comware 7 Virtual Services Router E-LTU
Features
Virtualization
Hypervisor suppport: supports the following industry-standard hypervisors:
VMware ESXi versions 4.1, 5.0, and 5.1; Linux KVM (Linux kernel version 2.6.25
or higher)
Recommended Linux operating systems: CentOS 6.3, Fedora 17, Ubuntu 12.10,
RedHat Enterprise Linux (RHEL) 6.3, and Suse Server 11SP2
Recommended vNICs: E1000 and virtIO virtual NICs are recommended
Maximum of 16 vNICs supported: provides flexible virtual connectivity
Layer 3 routing
Static IPv4 routing: provides simple, manually configured IPv4 routing
Static IPv6 routing: provides simple, manually configured IPv6 routing
Routing Information Protocol (RIP): uses a distance vector algorithm with UDP
packets for route determination; supports RIPv1 and RIPv2 routing; includes loop
protection
Routing Information Protocol next generation (RIPng): extends RIPv2 to
support IPv6 addressing
Open shortest path first (OSPF): delivers faster convergence; uses this
link-state routing Interior Gateway Protocol (IGP), which supports ECMP, NSSA,
and MD5 authentication for increased security and graceful restart for faster
failure recovery
Layer 3 services
Dynamic Host Configuration Protocol (DHCP): simplifies the management of
large IP networks
Domain Name System (DNS): provides a distributed database that translates
domain names and IP addresses, which simplifies network design; supports client
and server
Address Resolution Protocol (ARP): determines the MAC address of another IP
host in the same subnet
User Datagram Protocol (UDP) helper: redirects UDP broadcasts to specific IP
subnets to prevent server spoofing
Additional IP services: delivers forwarding/fast forwarding
(unicast/multicast), TCP, FTP server, FTP client, TFTP client, Telnet server,
Telnet client, and NTP/SNTP
Quality of Service (QoS)
Traffic classification: utilizes port, MAC address, IP address, IP priority,
DSCP priority, TCP/UDP port number, and protocol type
Traffic policing: supports committed access rate (CAR) and line rate (LR)
Traffic shaping: supports generic traffic shaping (GTS)
Congestion management: supports FIFO, weighted fair queuing (WFQ), and
class-based queuing (CBQ)
Congestion avoidance: supports tail drop and weighted random early detection
(WRED)
Specifications:
HP VSR1001 Virtual Services Router E-LTU
Networking
