All stock codes associated to this product
ARCHERT2UH, ARCHER T2UH, 2681953, 6935364050931
- 600 (433+150) Mbps wireless speed with 802.11ac
- High gain external antenna, remarkably strengthen signal power of the USB adapter
- Selectable Dual Band connections for lag-free HD video streaming and gaming
- Easy wireless security encryption at a push of the WPS button
- A tiny way to get speedy next generation Wi-Fi connections
- Supports Windows 8.1/8/7/XP,Mac OS X 10.7~10.10 and Linux
TP-LINK’s Archer T2UH comes with the next generation Wi-Fi standard – 802.11ac, 3 times faster than wireless N speeds. With 433Mbps wireless speeds over the crystal clear 5GHz band or 150Mbps over the 2.4GHz band, the Archer T2UH is the superior choice for seamless HD streaming, online gaming and other bandwidth-intensive tasks.
AC600 Wireless Speed
The 5GHz 433Mbps is perfect for HD video streaming and lag-free online gaming, while using 2.4GHz 150Mbps Wi-Fi for normal use such as web surfing.
The Best of Both Bands
TP-LINK’s Archer T2UH is an AC600 Wireless Dual Band USB Adapter, enabling you to easily access crystal clear 5GHz connections or legacy 2.4GHz connections, upgrading your notebook or PC’s wireless capabilities.
Bundled USB Extension Cable
Archer T2UH equipped with the 1m USB 2.0 extension cable, which extend the USB connection length, making it more convenient to plug the USB device in & out of the USB socket. Its elegant and stylish design is suitable for home deployment and will even improve the look of your home and office.
External Antenna
External antennas for easy alignment to achieve the best signal.
Specifications
| HARDWARE FEATURES |
|---|
| Interfaces |
USB 2.0 |
| Dimensions (W X D X H) |
3.7 x 1.0 x 0.4 in. (93.5 x 26 x 11mm) |
| Antenna Type |
Detachable Omni Directional (RP-SMA) |
| Antenna Gain |
3dBi |
| WIRELESS FEATURES |
| Wireless Standards |
IEEE 802.11ac, IEEE 802.11a,
IEEE 802.11n, IEEE 802.11g, IEEE 802.11b |
| Frequency |
5GHz
2.4GHz |
| Signal Rate |
5GHz
11ac: Up to 433Mbps(dynamic)
11n: Up to 150Mbps(dynamic)
11a: Up to 54Mbps(dynamic)
2.4GHz
11n: Up to 150Mbps(dynamic)
11g: Up to 54Mbps(dynamic)
11b: Up to 11Mbps(dynamic) |
| Reception Sensitivity |
5GHz:
11a 6Mbps: -94dBm
11a 54Mbps: -78dBm
11n HT20 MCS0: -94dBm
11n HT20 MCS7: -77dBm
11n HT40 MCS0: -92dBm
11n HT40 MCS7: -74dBm
11ac VHT80 MCS0: -89dBm
11ac VHT80 MCS9: -64dBm
2.4GHz:
11b 1Mbps: -99dBm
11b 11Mbps: -91dBm
11g 6Mbps: -94dBm
11g 54Mbps: -77dBm
11n HT20 MCS0: -95dBm
11n HT20 MCS7: -76dBm
11n HT40 MCS0: -92dBm
11n HT40 MCS7: -73dBm |
| Transmit Power |
<20dBm (EIRP) |
| Wireless Modes |
Ad-Hoc / Infrastructure mode |
| Wireless Security |
Support 64/128 bit WEP, WPA-PSK/WPA2-PSK, 802.1x |
| Modulation Technology |
DBPSK, DQPSK, CCK, OFDM, 16-QAM, 64-QAM, 256-QAM |
| OTHERS |
| Certification |
CE, FCC, RoHS |
| Package Contents |
Wireless Adapter Archer T2UH
Resource CD
Quick Installation Guide
USB Extension Cable |
| System Requirements |
Windows 8.1 (32/64bits), Windows 8 (32/64bits), Windows 7 (32/64bits), Windows XP (32/64bits),
Mac OS X 10.7~10.10, Linux |
| Environment |
Operating Temperature: 0?~40? (32?~104?)
Storage Temperature: -40?~70? (-40?~158?)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing |
