The Vigor2120 and Vigor2120n plus are broadband routers designed for
super-fast broadband. The Vigor2120 series are equipped with Gigabit
Ethernet WAN port and Gigabit Ethernet LAN switch for digital
entertainment and fast data transmission. The concurrent 2.4/5GHz WLAN
network allows you to have flexibility of using available bandwidth
within non-congested spectrum. The 5GHz spectrum is also very ideal for
home multimedia streaming. The Wireless LAN of Vigor2120n is with
versatile secure management to ensure better security. With the
dashboard of Web User Interface, you can promptly know the status of
broadband connection and relevant management mechanism. The Vigor2120
series’s USB port can also be used to add storage memory to the unit in
the form of a USB memory key or for higher capacity a USB hard drive
(which may require its own power). The Vigor2120 then provides access to
this memory by FTP from the WAN (remote Internet users) or users on
your own LAN.
Secure Networking
With Object-based firewall, you can use pre-define objects or groups
for IP, service type, key words, file extension, text, and mix these
with the Time Scheduler or the VLAN groups as required. By adoption of
the world-leading GlobalView Web Content Filtering, you can block whole
categories of web sites (e.g. sports, online shopping), subject to an
annual subscription to the GlobalView WCF, which is timely updated with
changed or new site categorizations. A free 30-day trial can be
activated via activation wizard of WUI. The Vigor2120 series support
more than 120Mbps IPSec VPN performance through 2 VPN tunnels(including
SSL VPN) which let you to establish remote data access from home or
remote office. The DrayTek VPN functionalities are multi-protocol such
as IPSec/PPTP/L2TP for most famous VPN servers. Even with 2 VPN tunnels,
you still can make VPN connections via LAN-to-LAN or remote access
along with brilliant Web-based applications.
DrayTek IPv6 solutions
We support Dual Stack (DHCPv6 Client, Static IPv6) and Tunnel Mode
(6in4, 6rd, AICCU, TSPC) to let your business operation successfully be
migrated to the era of IPv6.
Bandwidth management with intelligent VoIP QoS
The utilization of broadband bandwidth is very critical for business
operations. With VoIP QoS, the VoIP calls will be automatically
prioritized to let communications be smooth. You can manage the
bandwidth consumption of every employee based on the individual IP via
“Session Limit” and “Bandwidth Limit” settings.
Secured Wireless for Home or SOHO Networks
You can deploy a secured wireless LAN with WEP/WPA/WPA2 or a
discreted guest wireless with Multiple SSID and Wireless LAN isolation
to avoid from unauthorized access, hacking, and virus attachs.
Addintionally, the WMM (Wi-Fi Multimedia) keeps the priority of voice,
video and audio applications over the 2.4G/5G band. Whatever your
planned use is, the Vigor2120 series has WMM standards that let you game
a lot and spend much time enjoy streaming videos.
Multi-task USB functionalities
Through mobility, brought by cellular networks, you can connect
3.5G/4G USB mobile to 2.0 version USB port on Vigor2120 series. This can
be a backup broadband connection if the primary fixed line drops. You
can connect USB disk or hard-drive to USB port for memory storage and
file sharing. If you can not subscribe fixed line for Vigor2120 series,
you can subscribe 3.5G/or 4G USB mobile to connect it to USB port for
mobile broadband sharing.
Enterprise-level security for WLAN
You can deploy wireless LAN with security through WEP/WPA/WPA2, Mac
Address Control, Multiple SSID, Wireless LAN isolation and Wireless
VLAN. The WMM (Wi-Fi Multimedia) keeps the priority of voice, video and
audio applications in a Wi-Fi network. The Wireless Distribution System
(WDS) function allows you to extend the wireless coverage easily. The
proper wireless access control and wireless isolation can let your
employees and guests surf broadband with productivity. The “SSID VLAN
grouping with LAN port” settings will allow each of the wireless SSIDs
to be grouped within one of the VLANs.
Working with DrayTek TR-069 Central Management
If your main office self-hosts VigorACS SI central management, your Vigor2120 series can be remotely managed for firmware upgrade, alarm of disconnection, VPN establishment and other settings.
