All stock codes associated to this product
AP500, NWTLAP500, NWTL-AP500, 6935364092979
Overview
-
Simultaneous
600Mbps on 2.4GHz and 1300Mbps on 5GHz totals 1900Mbps Wi-Fi speeds, ideal for
4K streaming and online gaming
-
3
dual band detachable antennas provide superior Wi-Fi coverage to eliminate
dead zones
-
Beamforming
technology delivers highly targeted and efficient wireless connections
-
Gigabit
Ethernet port provides gigabit-class Internet access or an ultra-fast
connection for wired device
-
Dual
Core 1GHz processor ensures great performance, even with more devices
connected at the same time
-
Various
operation modes, including AP, Repeater/Bridge, Client, and Multi-SSID,
provide flexible solutions to meet the wireless needs in any
situation
Lightning-Fast AC1900 Dual Band Wi-Fi
Upgrade your home or office network with the latest-generation of dual band
802.11ac access point, which offers combined speeds of up to 1900Mbps and is
perfectly suited to serve multiple devices at the same time. The 5GHz band is
ideal for Ultra-HD streaming video and online gaming, while the 2.4GHz band is
there for all of your everyday Internet needs, like sending email and browsing
the Internet.
Superior Wifi Coverage
Three detachable antennas provide superior coverage to eliminate dead zones.
The addition of Beamforming Technology helps concentrate Wi-Fi signal strength
in the direction of connected devices to deliver a stable connection, even over
long distances.
Gigabit-Class Wired Performance
The Ethernet port can provide gigabit-class Internet access or an ultra-fast
connection for wired devices such as smart TVs, game consoles, etc.
1 GHz Dual-Core CPU Supports More Devices
The dual core Broadcom processor improves efficiency and performance by
dividing tasks between the cores, effectively allowing multiple things to be
done simultaneously.This ensures great performance, even when the AP500 is
serving numerous devices and performing multiple complex tasks at the same
time.
Easy
Setup and Use |
The AP500s powerful web interface allows it to be set up and configured in a
matter of minutes. The intuitive design makes installation faster and easier
than ever and allows users to monitor and personalize settings for a wide range
of functions.
Specifications
|
HARDWARE
FEATURES |
|
|
Interfaces |
1 * 10/100/1000Mbps
Ethernet Port (RJ45) |
|
Button |
WPS Button, Reset
Button, LED Button, Power Button |
|
Dimensions (W X D X
H) |
9.5 X 6.4 X 1.7 in.
(242 X 162 X 44mm) |
|
Antenna |
3 dual band detachable
antennas |
|
External Power
Supply |
12V/2.5A |
|
|
|
|
WIRELESS
FEATURES |
|
|
Wireless
Standards |
IEEE 802.11a/ac, IEEE
802.11b/g/n |
|
Frequency |
2.4GHz &
5GHz(11ac) |
|
Signal
Rate |
2.4GHz: Up to
600Mbps |
|
5GHz: Up to
1300Mbps |
|
Reception
Sensitivity |
2.4GHz: |
|
11g 54M: -76dBm@10%
PER |
|
11n HT20 MCS7:
-73dBm@10% PER |
|
11n HT40 MCS7:
-71dBm@10% PER |
|
5GHz: |
|
11a 6Mbps:-94dBm@10%
PER |
|
11a 54Mbps: -75dBm@10%
PER |
|
11ac HT20 MCS8:
-66dBm@10% PER |
|
11ac HT40 MCS9:
-62dBm@10% PER |
|
11ac HT80 MCS9:
-59dBm@10% PER |
|
Wireless
Modes |
Access Point, Repeater
(Range Extender)/Bridge with AP, Client, Multi-SSID |
|
Wireless
Functions |
Wireless Statistic,
Concurrent Mode boost both 2.4G/5G WiFi band, LED Control, Domain Login
Function |
|
Wireless
Security |
64/128-bit WEP,
WPA/WPA2, WPA-PSK / WPA2-PSK |
|
Transmission
Power |
CE: <20dBm(2.4GHz),
<23dBm(5GHz), FCC: <30dBm |
|
|
|
|
OTHERS |
|
Package
Contents |
AC1900 Wireless Gigabit
Access Point, AP500 |
|
3 Detachable
Antennas |
|
Power
Adapter |
|
RJ-45 Ethernet
Cable |
|
Desktop Mounting
Stand |
|
Quick Installation
Guide |
|
System
Requirements |
Microsoft Windows 98SE,
NT, 2000, XP, Vista or Windows 7, 8, 8.1, 10, Mac OS, NetWare, UNIX or
Linux. |
|
Environment |
Operating Temperature:
0C~40C (32F~104F) |
|
Storage Temperature:
-40C~70C (-40F~158F) |
|
Operating Humidity:
10%~90% non-condensing |
|
Storage Humidity:
5%~90% non-condensing |
|
Certifications |
CE, FCC,
RoHS |
