All stock codes associated to this product
T253L7120GTC101, 06TSSD120GBEVOL7, 06TSSD120GB-EVOL7
Features
- High performance Read speeds up to 500 MB/s to boost overall system
responsiveness and performance
- Slim form factor 2.5-inch drive available in 7mm to fit in more systems
(even slimmer notebooks)
- Supports S.M.A.R.T. monitors the status of your drive
- Supports TRIM maintains maximum performance of compatible operating
systems
- Supports DevSleep mode - conserve battery life
- Guaranteed 3-year warranty and free technical support
The best deal for a smart upgrade solution. Breathing new life into
your PC
Team Group L7 EVO solid state drive offers excellent transfer efficiency and
compatibility by applying the new generation Marvell controller chip, SATA III
6Gb/s specification and selected flash memory chips. The performance
requirements of any kind of motherboard, notebook and embedded device can be
fulfilled and the overall file transfer performance of PC can also be increased
comprehensively.
High
efficiency read/write performance gives you more with less |
L7 EVO SSD offers more efficient data read/write performance, lower power
consumption and a quiet operation experience. The problem of poor performance of
most PCs is not caused by poor CPU performance, but by the slow read speed of
the general hard drive. Upgrading to L7 EVO SSD can breathe new life into your
PC by speeding up its boots/shutdown time and enhancing multi-tasking
performance.
TRIM command supported to free its transfer performance
L7 EVO SSD supports Windows TRIM optimization command which is able to
release free blocks, allowing operating system to use them later immediately
when writing data. This can speed up the transfer and write performance of the
SSD, and also effectively reduce performance degradation and wear and tear of
the drive. It perfectly maintains the performance and prolongs the service life
of the SSD.
Low power consumption for longer use
L7 EVO SSD supports new generation of power saving technology: DevSleep
(Device Sleep Mode). It features ultra low power consumption, which turns off
the power of the SATA interface when computer goes into standby mode. It saves
more battery power and extends battery life, so you can back to work mode in no
time.
Trustworthy and reliable
L7 EVO SSDs built-in smart algorithm management mechanism has functions such
as garbage collection which is able to ensure operation efficiency and prolong
the service life of the SSD. Meanwhile, the powerful Wear-Leveling technology
and ECC (Error Correction Code) function enhance the reliability of data
transfer, making it a trusted and efficient assistant.
Specifications
|
Model |
L7
EVO |
|
|
|
Interface |
SATA Rev. 3.0 (6Gb/s)
with backwards compatibility to SATA Rev. 2.0 |
|
|
|
Capacity |
120 GB |
|
|
|
Voltage |
DC
5V |
|
|
|
Operation
Temperature |
0C ~
70C |
|
|
|
Performance |
ATTO / Crystal Disk
Mark: |
|
120GB Read: Up to
530MB/s Max ; Write: 360MB/s** |
|
240GB Read: Up to
530MB/s Max ; Write: 370MB/s** |
|
|
IOPS: |
|
120GB 4K Random
Read/Write: 25K/32K IOPS max** |
|
240GB 4K Random
Read/Write: 25K/33K IOPS max** |
|
|
|
Dimensions |
100 x 69.9 x 7
mm |
|
|
|
Humidity |
0C to 55C / 5% ~ 95%
RH,non-condensing |
|
|
|
Vibration |
20G
(non-operating) |
|
|
|
Shock |
1500G |
|
MTBF |
1,000,000
hours |
|
System
Requirements |
Windows 10 / 8 / 7 /
Vista, MAC OS 10.4 or later, Linux 2.6.33 or later
*** |
|
MTBF |
1,000,000
hours |
|
Warranty |
3-year limited
warranty |
