All stock codes associated to this product
TVS863+16G, TVS-863+-16G, QN17136
Features
Adorned with a box in gold color, the sophisticated TVS-863, featuring the
easy-to-use QTS operating system, is a powerful, reliable, secure and scalable
NAS solution designed for mission-critical and intensive business applications
and to meet fast growing data storage needs. The TVS-863 supports 10GbE via
optional PCI-E network expansion and delivers high performance with persistent
throughput, providing a comprehensive storage solution for SMBs to build a
reliable private cloud.
- 10GbE-ready, highly-efficient storage solution for HD video editing and
sharing
- Enhanced data security with a high-performance hardware-accelerated
encryption engine with AES 256-bit full NAS volume encryption and anti-virus
- Use the TVS-863 as a PC with exclusive QvPC Technology and 4K display
support
- Run multiple Windows/Linux/Android-based virtual machines with the
Virtualization Station
- Manage, share, and back up business data with Real-time Remote Replication
(RTRR)
- NAS and iSCSI-SAN(IP-SAN) unified storage solution for server
virtualization
- Supports VMware, Citrix, and Microsoft Hyper-V and advanced virtualization
features
- Transcode Full HD videos on-the-fly or offline with QNAPs unique
transcoding technology and hardware transcoding engine*
- Expand the total raw storage capacity up to 192TB with the economical
UX-800P QNAP expansion enclosures
High
performance & efficiency |
The TVS-863 is equipped with the energy-efficient 64-bit AMD quad-core 2.4
GHz processor with 4GB DDR3L-1600 RAM (upgradable to 16GB), SATA 6Gb/s, and 2
Gigabit LAN ports (expandable to max. 4 x GbE ports or 2 x GbE + 2 x 10GbE
ports) for lightning-fast multi-tasking. The TVS-863 is a powerful NAS that
delivers up to 824MB/s read & write speeds with 4 x GbE port configuration,
and up to 1,432MB/s with 10GbE configuration. The TVS-863s hardware-accelerated
encryption engine with AES-NI provides unmatched encryption performance in its
class, up to 718MB/s with AES 256- bit full NAS volume encryption, boosting
system performance & security while ensuring the safety of sensitive
business data stored in the TVS-863. The next-gen AMD RadeonHD
graphics provides hardware-accelerated transcoding performance and dual HDMI
outputs with brilliant high-definition multimedia content playback. When
installed with the latest Wi-Fi 802.11ac USB network adapter, the TVS-863 can
offer remarkably high speeds for transferring large amount of files and
streaming bandwidth-consuming multimedia.
QTS -
Simple and efficient |
Thanks to the intuitive user interface of QTS, system operations of the
TVS-863 are smooth and handy. Its intelligent desktop allows you to find desired
functions quickly, create desktop shortcuts or group shortcuts, monitor
important system information on a real-time basis, and open multiple application
windows to run multiple tasks concurrently, bringing greater operating
efficiency.
Qsirch A
smarter, faster way to search |
Quickly and easily find documents, photos, videos, and music with Qsirch,
QNAPs new built-in NAS search application lets you find what you need by
real-time, natural search. Simply type in as much as you know about what you are
trying to find, including bits of the file name or even words/phrases in the
document, and Qsirch will display a list of matches, complete with thumbnails,
as you type. Qsirch even remembers your search history so you can quickly
navigate to files youve previously searched for. Qsirch is a huge productivity
boost it greatly reduces the amount of time spent looking for files on the NAS
so you can focus on other tasks.
| 10GbE
ready |
The TVS-863 offers 2 inbuilt Gigabit Ethernet ports and supports 10 Gigabit
high speed networks by installing a 10GbE network adapter. The 10GbE-ready
TVS-863 delivers lightning-fast data throughput. Coupled with its large storage
capacity potential, the TVS-863 is perfect for data centers to store big data
and excel in fast data transmission, and for 10GbE home lab environment for
technical professionals.
Specifications
CPU |
AMD 2.4GHz quad-core
x86 processor with Radeon graphics |
DRAM |
TVS-863-4G: 4GB
DDR3L-1600 x 1 |
|
TVS-863-8G: 8GB
DDR3L-1600 x 1 |
|
|
|
Total memory slots:
2 |
|
Memory expandable up
to: 16 GB (8GB x2) |
Flash
Memory |
512MB
DOM |
Hard Disk
Drive |
8 x 3.5or 2.5SATA
6Gb/s, SATA 3Gb/s hard drive or SSD |
Hard Drive
Tray |
8 x Hot-swappable
tray |
LAN
Port |
2 x Gigabit RJ-45
Ethernet port (Onboard:2, expandable to max 4 ports via PCI-E
NIC) |
PCIe
Slot |
1 (PCIe Gen2 x
4) |
LCD
Panel |
Mono-LCD display with
backlight, Enter and Select buttons for configuration |
LED
Indicators |
Status, LAN, USB, HDD
1-8 |
USB |
5 x USB 3.0 port
(Front: 1, Rear: 4) |
|
Support USB printer,
pen drive, and USB UPS etc. |
HDMI |
2 (Mirrored Display),
1.4a |
|
Note: 4K video playback
and transcoding are not supported |
Buttons |
Power/Status, USB
One-Touch-Backup, reset |
Alarm
Buzzer |
System
warning |
IR
Receiver |
QNAP RM-IR002 and
MCE-compatible remotes |
Form
Factor |
Tower |
Dimensions |
185.2(H) x 298.2(W) x
235.4(D) mm |
|
7.29(H) x 11.74(W) x
9.27(D) inch |
Weight |
Net:7.83 kg
(17.26lbs) |
|
Gross: 8.9 kg
(19.62lbs) |
Power
Consumption(W) |
S3 sleep:
2.35W |
|
HDD standby:
46.21W |
|
In operation:
70.45W |
|
(with 8 x 2TB HDDs
installed) |
Sound
Level* |
Sound pressure (LpAm):
21.3 dB(A) |
Temperature |
0-40C |
Humidity |
5~95% RH
non-condensing, wet bulb: 27C |
Power
Supply |
ATX 250W, 110-240V AC,
50-60Hz, 5A |
Secure
Design |
Kensington security
slot for theft prevention |
Fan |
2 x quiet cooling fan
(12cm, 12V DC) |
Software Specs.
Powerful All-in-one
server
