Features
- Complies with IEEE 802.3/802.3u standards
- Complies with USB 2.0/1.1 specifications
- Supports 10/100Mbps auto-negotiation
- Low power consumption in idle mode and low traffic conditions
- No external power adapter required
- Supports Windows 2000/XP/Vista/7/8/8.1, Linux and Mac OS X 10.x
The Edimax EU-4208 is a compact USB Fast Ethernet adapter for an Ultrabook or
Macbook Airwith no Ethernet ports, or for desktop and notebooks that need an
additional Fast Ethernet port. Its an ideal portable accessory or replacement
network adapter, and with full 10/100Mbps Fast Ethernet USB 2.0 performance, its
faster than most wireless connections. Connect to a 10/100Mbps network from a
USB enabled desktop or notebook, save costs and replace an old or broken
internal network card, or use it as an additional network interface for
high-speed peer-to-peer file sharing. No external power adapter is required and
the green, energy-saving design minimizes power usage when the device is
idle.
Ideal for Ultrabooks
Designed to give Fast Ethernet connectivity to your Ultrabook, Macbook Air or
any computer without an Ethernet port. Simply plug the adapter into a USB 2.0
port and instantly utilize a stable 10/100Mbps Ethernet connection. The EU-4208
is also a quick and convenient way to add Ethernet connectivity to a desktop
computer without the hassle of internal installation. Its backward compatible
with USB 1.1 and works with Microsoft Windows 2000/XP/Vista/7/8/8.1, Linux and
Mac OS X 10.x.
USB 2.0 for Full 10/100Mbps Ethernet Performance
Compared to USB 1.1 adapters which only offer 12Mbps transmission speeds, the
EU-4208 is designed with the USB 2.0 standard which supports data transfer
speeds up to 480Mbps, ensuring full 10/100Mbps Ethernet performance without any
compromise.
Compact Design & Power over USBT
The Edimax EU-4208 features a compact design, making it easy to use in a
crowded workspace. And with power over USB support, the EU-4208 works without
the need for an additional power adapter.
Low Power Consumption
The Edimax EU-4208 is designed to use power efficiently and prevent
unnecessary waste of power. It can dynamically adjust its power supply for
reduced power usage in idle mode and low traffic conditions.
Windows 8.1 & Mac OS X 10.x
Full compatibility with Windows 8.1 and Mac OS X 10.x for hassle-free use
with brand new devices and future-proof peace of mind.
Specifications
|
Hardware |
Standards |
RAM |
|
1 x USB 2.0 (USB 1.1
backward compatible) |
IEEE
802.3 |
Embedded 20KB SRAM for
RX and 20KB SRAM for TX packet buffering |
|
1 x RJ-45 10/100Mbps
LAN port |
IEEE
802.3u |
|
Power and link LED
indicators |
|
|
Power
Consumption |
Power
Management |
Operating
Temperature |
|
600mW (full
loading) |
Idle mode (remote wake
up enabled) |
0-70 degrees
Celsius |
|
46.1mW (idle with
remote wake up) |
Idle mode (remote wake
up disabled) |
|
0.7mW (idle without
remote wake up) |
|
|
Operating
System |
Dimensions &
Weight |
Certification |
|
Windows 2000, XP,
Vista, 7, 8, 8.1 |
66 x 22 x 15 mm (L x W
x H) |
FCC,
CE |
|
Linux |
23.5g |
|
Mac OS X
10.x |
|
Package Contents
- USB 2.0 Fast Ethernet Adapter x 1
- Quick installation guide x 1
- CD with setup wizard, user manual & multilanguage QIG x
1
