Simultaneous Dual-Band Wi-Fi
The UniFi AP-PRO supports up to 300 Mbps, 2x2 MIMO for the 5 GHz band and up to 450 Mbps, 3x3 MIMO for the 2.4 GHz band.
Scalability for Thousands
With its software-based capabilities, the UniFi virtual control plane allows for unlimited scalability under one centralized controller.
Rapid Deployment
Plug and Play installation and intuitive management reduce the need for dedicated IT personnel resources.
Affordable Enterprise Wireless
The UniFi AP is available for less than $100 USD MSRP, delivering high-performance Wi-Fi in a streamlined form factor.
No Software Fees
The UniFi Controller software is bundled with the UniFi AP hardware at no extra chargre - no separate software, licensing or support fee.
Scalable Enterprise Wi-Fi Management
The UniFi Controller software is a powerful, enterprise wireless software engine ideal for high-density client deployments requiring low latency and high uptime performance. A single UniFi Controller running in the cloud can manage multiple sites: multiple, distributed deployments and multi-tenancy for managed service providers.
Advanced Software Features
Intuitive and Robust Configuration, Control and Monitoring
Instantly provision and configure thousands of UniFi APs. Quickly manage system traffic.
Custom Maps and Google Maps
Upload custom map images or use Google Maps for a visual representation of your wireless network.
WLAN Groups
Take advantage of WLAN groups for flexible configuration of large deployments and enable wireless connection between APs to extend range.
Outdoor Model Comparison Chart
Specifications
|
UniFi AP
|
|
Dimensions
|
200 x 200 x 36.5 mm
(7.87 x 7.87 x 1.44 in)
|
|
Weight
|
290 g (10.23 oz)
without Mounting Kits
430 g (15.17 oz)
with Mounting Kits
|
|
Networking Interface
|
(1) 10/100 Ethernet
Port
|
|
Buttons
|
Reset
|
|
Operating Band
|
2.4 GHz
|
|
Antennas
|
Integrated 3 dBi
Omni (Supports 2x2 MIMO with Spatial Diversity)
|
|
Wi-Fi Standards
|
802.11 b/g/n
|
|
Power Method
|
Passive Power over
Ethernet (12-24V)
|
|
Power Supply
|
24V, 0.5A PoE
Adapter Included
|
|
Maximum Power Consumption
|
4W
|
|
Maximum TX Power
|
20 dBm
|
|
BSSID
|
Up to Four Per Radio
|
|
Power Save
|
Supported
|
|
Wireless Security
|
WEP, WPA-PSK,
WPA-Enterprise (WPA/WPA2, TKIP/AES)
|
|
Certifications
|
CE, FCC, IC
|
|
Mounting
|
Wall/Ceiling (Kits
Included)
|
|
Operating Temperature
|
-10 to 70° C (14 to
158° F)
|
|
Operating Humidity
|
5 - 80%
Noncondensing
|
|
Advanced Traffic Management
|
|
VLAN
|
802.1Q
|
|
Advanced QoS
|
Per-User Rate Limiting
|
|
Guest Traffic Isolation
|
Supported
|
|
WMM
|
Voice, Video, Best Effort,
and Background
|
|
Concurrent Clients
|
100+
|
|
Supported Data Rates (Mbps)
|
|
Standard
|
Data Rates
|
|
802.11n
|
6.5 Mbps to 300 Mbps
(MCS0 - MCS15, HT 20/40)
|
|
802.11b
|
1, 2, 5.5, 11 Mbps
|
|
802.11g
|
6, 9, 12, 18, 24,
36, 48, 54 Mbps
|
Networking
