All stock codes associated to this product
MZ750500BW, MZ-750500BW, 8806088409825
Overview
Features
Boost your computing experience with fast performance
PC users are choosing high-speed SSDs for better computing performance and
reliability. The Samsung SSD 750 EVO, with a SATA 6 GB/s interface, is an
outstanding high-performance choice for an everyday computing experience. With
sequential read and write speeds up to 540/520 MB/s and random read and write
speeds up to 97,000/88,000 IOPS1, you will find yourself handling multitasking
exceptionally fast
Enjoy exceptional computing for everyday use
The Samsung SSD 750 EVO boasts a fast computing experience thanks to
TurboWrite technology and RAPID mode. TurboWrite technology accelerates
sequential write speeds by creating a write buffer inside the SSD. Magician
software provides the option to enhance PC performance with RAPID mode, which
processes data on a system level using unused PC memory (DRAM) as a cache.
Secure data through advanced data encryption
The Samsung SSD 750 EVO features SED2technology to help keep your data safe.
An AES-256-bit hardware-based full disk encryption engine helps to secure your
data with less performance degradation than some software-based encryption
products. And the Samsung SSD 750 EVO is compliant with TCG3Opal v2.0 standards
and IEEE41667 protocol.
Depend on solid reliability wherever life takes you
The flash-based Samsung SSD 750 EVO provides excellent resistance against
shock and vibration for computing on the go. Samsung guarantees this SSD for 3
years, or up to 35 Total Bytes Written (TBW) for the 120 GB model and 70 TBW for
the 250 GB model5.
Discover easy installation and SSD management
The Samsung SSD 750 EVO comes with software to help entry-level users easily
install and manage their SSDs. Samsung Data Migration software provides a
powerful custom-cloning feature that helps to ensure migration works even when
the source data is greater than the SSD capacity. And Magician software
simplifies SSD management, enabling even novices to maximize the performance and
lifetime of the SSDs.
Specifications
|
Application |
Client
PCs |
|
Capacity |
500 GB (1GB=1
Billionbyte by IDEMA) *Actual usable capacity may be less (due to
formatting, partitioning, operating system, applications or
otherwise) |
|
Form
Factor |
2.5
inch |
|
Interface |
SATA 6Gb/s Interface,
compatible with SATA 3Gb/s & SATA 1.5Gb/s
interface |
|
Dimension
(WxHxD) |
100 X 69.85 X 6.8
(mm) |
|
Weight |
Max
45.0g |
|
Controller |
Samsung MGX
controller |
|
Cache
Memory |
Samsung 256MB DDR3
DRAM |
|
TRIM
Support |
TRIM
Supported |
|
S.M.A.R.T
Support |
S.M.A.R.T
Supported |
|
GC (Garbage
Collection) |
Auto Garbage Collection
Algorithm |
|
Encryption
Support |
AES 256-bit Full Disk
Encryption (FDE) TCG/Opal v2.0, Encrypted Drive
(IEEE1667) |
|
WWN
Support |
Yes |
|
Device Sleep Mode
Support |
Yes |
|
Sequential
Read |
Up to 540 MB/sec
Sequential Read *Performance may vary based on system hardware &
configuration |
|
Sequential
Write |
Up to 520 MB/sec
Sequential Write *Performance may vary based on system hardware &
configuration |
|
Random Read (4KB,
QD32) |
Up to 97,000 IOPS
Random Read *Performance may vary based on system hardware &
configuration |
|
Random Write (4KB,
QD32) |
Up to 88,000 IOPS
Random Write *Performance may vary based on system hardware &
configuration |
|
Random Read (4KB,
QD1) |
Up to 10,000 IOPS
Random Read *Performance may vary based on system hardware &
configuration |
|
Random Write (4KB,
QD1) |
Up to 35,000 IOPS
Random Write *Performance may vary based on system hardware &
configuration |
|
Reliability
(MTBF) |
1.5 Million Hours
Reliability (MTBF) |
|
Operating
Temperature |
0C to 70C (Measured by
SMART Temperature. Proper airflow recommended) |
|
Shock |
1500G, duration 0.5m
sec, 3 axis |
|
Management
SW |
Magician Software for
SSD management |
|
Installation
Kit |
Not
Available |
|
Warranty |
3 Year Limited Warranty
or 70TBW Limited Warranty |
