Hardware Features |
|
|
Interface |
1 10/100/1000Mbps RJ45 LAN/WAN Port, |
|
3 10/100/1000Mbps RJ45 LAN Ports, |
|
3 RJ11 Ports (DSL, FON1/FON2), |
|
2 TAE Ports, |
|
1 USB 2.0 Port |
|
Button |
WPS, Wi-Fi On/Off , Reset, LED, Power On/Off, DECT |
|
External Power Supply |
12V/2A |
|
IEEE Standards |
IEEE 802.3, IEEE 802.3u, 802.3ab |
|
VDSL2 Standards |
ITU-T G.993.2, Up to 17a profile (POTS), |
|
ITU-T G.993.5 (G.vector), |
|
ITU-T G.998.4 (G.INP |
|
ADSL Standards |
Full-rate-ANSI T1.413 Issue 2, |
|
ITU-T G.992.1 (G.DMT), |
|
ITU-TG.992.2 (G.Lite), |
|
ITU-T G.994.1 (G.hs), |
|
ITU-T G.995.11 |
|
ADSL2 Standards |
ITU-T G.992.3 (G.DMT.bis), |
|
ITU-T G.992.4 (G.lite.bis) |
|
ADSL2+ Standards |
ITU-T G.992.5 (Annex B und J) |
|
Dimensions ( W x D x H ) |
215.8 163.7 36.8 mm |
|
Antenna Type |
3 external detachable dual band antennas (RP-SMA) |
|
Antenna Gain |
3 x 2dBi for 2.4GHz and 3 x 3dBi for 5GHz |
|
WIRELESS FEATURES |
|
|
Wireless Standards |
IEEE 802.11ac/n/a 5GHz, IEEE 802.11b/g/n 2.4GHz |
|
Wireless Speeds |
1300Mbps at 5GHz, 300Mbps at 2.4GHz |
|
Frequency |
2.4GHz and 5GHz |
|
Transmit Power |
<20dBm (2.4GHz), |
|
<23dBm (5GHz Band1 & Band2), |
|
<30dBm (5GHz Band3) |
|
Wireless Functions |
Enable/Disable Wireless Radio, |
|
WMM, |
|
Wireless Statistics, |
|
Support 2.4GHz and 5GHz Wireless Schedule |
|
Wireless Security |
64/128-bit WEP,WPA/WPA2,WPA-PSK/WPA-PSK2
encryptions |
|
VoIP FEATURES |
|
|
VoIP Standards |
SIP(RFC3261)/RTP(RFC1889/3550), G.711A/u, G.722, |
|
G.729AB, G.726 |
|
DECT Function |
DECT base station for up to 6 cordless phones, |
|
Compatible with CAT-iq and GAP, Supoorts paging
function |
|
Software Features |
|
|
Quality of Service |
ATM QoS, Traffic Control (IP QoS) |
|
Security |
NAT Firewall, SPI Firewall, Access Control, Service Filtering, Denial
of Service (DoS), SYN Flooding, Ping of Death, IP and MAC Address
Binding |
|
Operating Modes |
VDSL/ADSL Modem Router, Wireless Router |
|
Management |
Web Based Configuration (HTTP / HTTPS ), Remote management, Command
Line Interface, SSL for TR-069, SNMP v1/2c, Firmware Upgrade, Diagnostic
Tools, Free Online Firmware Update |
|
DHCP |
Server, Client, DHCP Client List, Address Reservation, DHCP
Relay |
|
Port Forwarding |
Virtual Server, Port Triggering, DMZ, ALG, UPnP |
|
Dynamic DNS |
TP-Link / Dyndns / noip / DuckDNS / DtDNS / yDNS / freeDNS / DYNU /
AnyDNS /Selfhost / spdns / custom |
|
VPN |
OpenVPN, PPTP VPN, IPSec VPN |
|
Protocols |
Support IPv4 and IPv6 |
|
ATM/PPP Protocols |
ATM Forum UNI3.1/4.0, PPP over ATM (RFC 2364), PPP over Ethernet
(RFC2516), IPoA (RFC1577/2225), MER\IPoE (RFC 1483 Routed), Bridge
(RFC1483 Bridge), PVC Up to 8 PVCs |
|
Advanced Features |
Parental Controls, Network Address Translation(NAT), Port
Mapping(Grouping), Static Routing, RIP v1/v2 (optional), DNS Relay, DDNS,
IGMP V1/V2/V3 |
|
USB Sharing |
Support Samba (Storage) / FTP Server / Media Server / Printer Server /
SFTP Server / Web Storage |
|
Guest Network |
2.4GHz guest network, 5GHz guest network |
|
IPSec VPN |
Support up to 10 IPSec VPN tunnels |
|
Others |
|
|
Package Contents |
AC1600 WLAN Telefon DSL Router Archer VR600v |
|
RJ45-RJ11 Cable |
|
TAE-RJ45 Adapter |
|
RJ45 Ethernet Cable |
|
Power Adapter |
|
Quick Installation Guide |
|
Telephony Feature Guide |
|
System Requirements |
Microsoft Windows 98SE, NT, 2000, XP, Vista or Windows 7, 8, 8.1,
10, |
|
Mac OS, NetWare, UNIX or Linux |
|
Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or
other |
|
Java-enabled browser |
|
Subscription with an internet service provider (for internet
access) |
|
Environment |
Operating Temperature: 0 DegreeC~40 DegreeC (32 DegreeF~104 DegreeF) |
|
Storage Temperature: -40 DegreeC~70 DegreeC(-40 DegreeF ~158
DegreeF) |
|
Operating Humidity: 10%~90% non-condensing |
|
Storage Humidity: 5%~90% non-condensing |
|
Certifications |
CE, RoHS |
