Standard
Model Numbers |
ST12000VN0008 |
Interface |
SATA
6Gb/s |
Features
and Performance |
|
Drive
Bays Supported |
1-8
Bays |
Multi-User
Technology |
180TB/year |
Rotational
Vibration (RV) Sensor |
Yes |
Rotational
Vibration (RV) Sensor |
Yes |
Error
Recovery Control |
Yes |
Max.
Sustained Transfer Rate OD (MB/s) |
210MB/s |
Spindle
Speed (RPM) |
7200 |
Cache
(MB |
256 |
Reliability |
|
Load/Unload
Cycles |
600,000 |
Nonrecoverable
Read Errors Rate, Max |
1
per 10E15 |
Power-On
Hours |
8760 |
Workload
Rate Limit (WRL) |
180 |
Mean
Time Between Failures (MTBF, hours) |
1,000,000 |
Limited
Warranty (years) |
3 |
Power
Management |
|
Startup
Current, Typical (12V, A) |
1.8 |
Average
Operating Power (W) |
7.8W |
Idle
Average (W) |
5.0W |
Standby
Mode/Sleep Mode, Typical (W) |
0.8/0.8 |
Voltage
Tolerance, Inc. Noise (5V) |
±5% |
Voltage
Tolerance, Inc. Noise (12V) |
±10% |
Environmental/Temperature |
|
Operating
(ambient, min °C) |
5 |
Operating
(drive case, max °C) |
70 |
Nonoperating
(ambient, min °C) |
40 |
Nonoperating
(ambient, max °C) |
70 |
Halogen
Free |
Yes |
Environmental/Shock |
|
Shock,
Operating/Nonoperating: 2ms (max) |
70Gs/250Gs |
Environmental/Acoustics |
|
Idle
(typical) |
1.8bels |
Seek
(typical) |
2.8bels |
Physical |
|
Height
(mm/in) |
26.11mm/1.028in |
Width
(mm/in, max) |
101.85mm/4.01in |
Depth
(mm/in, max) |
146.99mm/5.787in |
Weight
(g/lb, typical) |
690g/1.521lb |
Carton
Unit Quantity |
20 |
Cartons
per Pallet/Cartons per Layer |
40/8 |
