       Specifications  |

       16
  TB  |

    |
       Capacity  |

       16TB  |

    |
       Standard Model
      Number  |

       ST16000VN001  |

    |
       Interface  |

       SATA
      6Gb/s  |

     |
     |
     |
     |
     |

    |
       Features and
      Performance  |

    |
       Drive Bays
      Supported  |

       1 8
    Bays  |

    |
       Multi-User
      Technology  |

       180
      TB/year  |

    |
       Rotational Vibration
      (RV) Sensor  |

       Yes  |

    |
       Dual-Plane
      Balance  |

       Yes  |

    |
       Error Recovery
      Control  |

       Yes  |

    |
       Max. Sustained Transfer
      Rate OD (MB/s)  |

       210MB/s  |

    |
       Spindle Speed
      (RPM)  |

       7,200  |

    |
       Cache
      (MB)  |

       256  |

     |
     |
     |
     |
     |

    |
       Reliability  |

    |
       Load/Unload
      Cycles1  |

       600,000  |

    |
       Non-recoverable Read
      Errors Rate, Max  |

       1 per
      10E15  |

    |
       Power-on
      Hours  |

       8,760  |

    |
       Workload Rate Limit
      (WRL)  |

       180  |

    |
       Mean Time Between
      Failures (MTBF, hours)  |

       1,000,000  |

    |
       Limited Warranty
      (years)  |

       3  |

     |
     |
     |
     |
     |

    |
       Power
      Management  |

    |
       Startup Current,
      Typical (12V, A)  |

       1.8  |

    |
       Average Operating Power
      (W)  |

       7.3
  W  |

    |
       Idling Average
      (W)  |

       5.3
  W  |

    |
       Standby Mode/Sleep
      Mode, Typical (W)  |

       0.8/0.8  |

    |
       Voltage Tolerance, Inc.
      Noise (5 V)  |

       5%  |

    |
       Voltage Tolerance, Inc.
      Noise (12 V)  |

       10%  |

     |
     |
     |
     |
     |

    |
       Environmental/Temperature  |

    |
       Operating (ambient, min
      C)  |

       5  |

    |
       Operating (drive case,
      max C)2  |

       70  |

    |
       Non-operating (ambient,
      min C)  |

       -40  |

    |
       Non-operating (ambient
      max C)  |

       70  |

    |
       Halogen-free  |

       Yes  |

     |
     |
     |
     |
     |

    |
       Environmental/Shock  |

    |
       Shock,
      Operating/Non-operating: 2 ms (max)  |

       50Gs/200Gs  |

     |
     |
     |
     |
     |

    |
       Environmental/Acoustics  |

    |
       Idle
      (typical)3  |

       2.8
    bels  |

    |
       Seek
      (typical)  |

       3.0bels  |

     |
     |
     |
     |
     |

    |
       Physical  |

    |
       Height
      (mm/in)  |

       26.11 mm/1.028
      in  |

    |
       Width (mm/in,
      max)  |

       101.85 mm/4.01
      in  |

    |
       Depth (mm/in,
      max)  |

       146.99 mm/5.787
      in  |

    |
       Weight (g/lb,
      typical)  |

       670 g/1.477
      lb  |

    |
       Carton Unit
      Quantity  |

       20  |

    |
       Cartons per Pallet /
      Cartons per Layer  |

       40/8  |
