Basic
Specs |
|
|
DOCUMENT SIZE -
MULTIPLE PAPERS - WIDTH |
51 mm to 215.9
mm |
|
DOCUMENT SIZE -
MULTIPLE PAPERS - LENGTH |
70 mm to 863
mm |
|
DOCUMENT SIZE - SINGLE
PAPER - WIDTH |
51 mm to 215.9
mm |
|
DOCUMENT SIZE - SINGLE
PAPER - LENGTH |
70 mm to 863
mm |
|
COLOUR /
BLACK |
Yes/Yes |
|
DUPLEX
SCAN |
Yes |
|
COLOR DEPTH -
INPUT |
48-bit colour
processing |
|
COLOR DEPTH -
OUTPUT |
24-bit colour
processing |
|
RESOLUTION -
OPTICAL |
Max. 600 dpi 600
dpi |
|
RESOLUTION -
INTERPOLATED |
Max. 1,200 dpi 1,200
dpi |
|
SCANNING
WIDTH |
Max.216
mm |
|
GRAYSCALE |
256
levels |
|
PRODUCT DIMENSIONS
(WIDTH X DEPTH X HEIGHT) |
300 mm x 103 mm x 83
mm |
|
WARRANTY |
1 year Return to Base
Warranty |
|
General |
|
|
MEMORY
CAPACITY |
SDRAM: 512
MB |
|
ADF (AUTOMATIC DOCUMENT
FEEDER) |
Up to 20
sheets |
|
WEIGHT |
1.4
kg |
|
Display |
|
|
TOUCHSCREEN LCD (LIQUID
CRYSTAL DISPLAY) |
7.1cm LCD colour
touchscreen |
|
Operation |
|
|
POWER
SOURCE |
AC: 220 - 240 V, 50/60
Hz |
|
POWER CONSUMPTION -
SCANNING |
Approx.
9W |
|
POWER CONSUMPTION -
READY |
Approx.
4.5W |
|
POWER CONSUMPTION -
POWER SAVING / DEEP SLEEP |
Approx.
1.5W |
|
POWER CONSUMPTION -
POWER OFF |
Approx.
0.1W |
|
TEMPERATURE -
OPERATING |
5C to
35C |
|
HUMIDITY -
OPERATING |
20% to
80% |
|
HUMIDITY -
STORAGE |
10% to
90% |
|
Compliance |
|
|
TWAIN COMPLIANT -
WINDOWS |
Windows 7
SP1/8/8.1/10 |
|
Server2008 R2
SP1/2012/2012 R2/2016 |
|
TWAIN COMPLIANT - MAC
OS |
MacOS
v10.11.6/10.12x/10.13x |
|
WIA COMPLIANT -
WINDOWS |
Windows 7
SP1/8/8.1/10 |
|
Server2008 R2
SP1/2012/2012 R2/2016 |
|
ICA COMPLIANT - MAC
OS |
MacOS
v10.11.6/10.12x/10.13x |
|
Interface |
|
|
USB |
Hi-Speed
USB2.0 |
|
Superspeed
USB3.0 |
|
WIRELESS
LAN |
Wireless Network TCP/IP
(IPv4) (IPv6) IEEE 802.11b/g/n (Infrastructure Mode), IEEE 802.11g (Wi-Fi
Direct) |
|
Network |
|
|
WIRELESS NETWORK
SECURITY |
WEP 64/128-bit, WPA-PSK
(TKIP/AES), WPA2-PSK (AES) |
|
SETUP SUPPORT
UTILITY |
WPS |
