Processor |
---|
Processor generation | 2nd Generation Intel® Xeon® Scalable |
Thermal Design Power (TDP) | 85 W |
Tcase | 77 °C |
Supported instruction sets | AVX-512 |
Scalability | 2S |
Processor threads | 24 |
Processor package size | 76.0 x 56.5 mm |
Processor operating modes | 64-bit |
Processor lithography | 14 nm |
Processor codename | Cascade Lake |
Processor cache type | Smart Cache |
Memory types supported by processor | DDR4-SDRAM |
Memory clock speeds supported by processor | 2400 MHz |
Maximum number of PCI Express lanes | 48 |
Maximum internal memory supported by processor | 1024 GB |
Execute Disable Bit | Yes |
Embedded options available | Yes |
Processor cache | 16.5 MB |
Processor frequency | 2.2 GHz |
Processor family | Intel Xeon Silver |
Processor model | 4214 |
Processor cores | 12 |
Number of processors installed | 1 |
Processor boost frequency | 3.2 GHz |
Processor socket | LGA 3647 (Socket P) |
Processor manufacturer | Intel |
Memory |
---|
Internal memory | 16 GB |
Maximum internal memory | 768 GB |
Internal memory type | DDR4-SDRAM |
Memory slots | 24x DIMM |
Memory clock speed | 2933 MHz |
Buffered memory type | Registered (buffered) |
Storage |
---|
HDD interface | Serial ATA, Serial Attached SCSI (SAS) |
RAID support | Yes |
RAID levels | 0, 1, 5, 10 |
Supported HDD sizes | 3.5" |
Optical drive type | No |
Number of HDDs supported | 12 |
Graphics |
---|
On-board graphics card model | Not available |
Network |
---|
LAN controller | HP 331i |
Ethernet LAN | Yes |
Ethernet interface type | Gigabit Ethernet |
Cabling technology | 10/100/1000Base-T(X) |
Ports & interfaces |
---|
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
Ethernet LAN (RJ-45) ports | 4 |
DisplayPorts quantity | 1 |
Expansion slots |
---|
PCI Express slots version | 3.0 |
Design |
---|
Chassis type | Rack (2U) |
Redundant fans support | Yes |
Rack mounting | Yes |
Optical drive type | No |
Performance |
---|
Operating system installed | No |
Compatible operating systems | Windows Server 2019 |
Harmonized System (HS) code | 84714100 |
Software |
---|
Operating system installed | No |
Compatible operating systems | Windows Server 2019 |
Processor special features |
---|
Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
Intel VT-x with Extended Page Tables (EPT) | Yes |
Intel Virtualization Technology (VT-x) | Yes |
Intel® Turbo Boost Technology | 2.0 |
Intel TSX-NI | Yes |
Intel Trusted Execution Technology | Yes |
Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
Intel® AES New Instructions (Intel® AES-NI) | Yes |
Intel 64 | Yes |
Processor ARK ID | 193385 |
Enhanced Intel SpeedStep Technology | Yes |
Power |
---|
Redundant power supply (RPS) support | Yes |
Number of main power supplies | 1 |
Power supply | 800 W |
Technical details |
---|
Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
Harmonized System (HS) code | 84714100 |
Sustainability certificates | ENERGY STAR |
Weight & dimensions |
---|
Width | 445.5 mm |
Weight | 14.8 kg |
Height | 87.4 mm |
Depth | 730.3 mm |
