Processor |
---|
Processor generation | Intel® Pentium® Gold |
Idle States | Yes |
Execute Disable Bit | Yes |
Embedded options available | No |
Processor cache | 4 MB |
Processor frequency | 4.1 GHz |
Processor family | Intel® Pentium® Gold |
Processor model | G6405 |
Processor cores | 2 |
Number of processors installed | 1 |
Processor manufacturer | Intel |
Motherboard chipset | Intel C252 |
Memory |
---|
Internal memory | 16 GB |
Maximum internal memory | 64 GB |
Internal memory type | DDR4-SDRAM |
Memory slots | 2x DIMM |
Memory layout (slots x size) | 1 x 16 GB |
Memory clock speed | 2666 MHz |
ECC | Yes |
Storage |
---|
HDD interface | SATA |
RAID support | Yes |
RAID levels | 0, 1, 5, 10 |
Supported HDD sizes | 3.5" |
Optical drive type | No |
Number of HDDs supported | 4 |
Maximum storage capacity | 16 TB |
Hot-Plug support | No |
Network |
---|
LAN controller | Intel® I350-AM4 |
Ethernet LAN | Yes |
Ethernet interface type | Gigabit Ethernet |
Ports & interfaces |
---|
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
USB 2.0 ports quantity | 1 |
VGA (D-Sub) ports quantity | 1 |
Ethernet LAN (RJ-45) ports | 4 |
DisplayPorts quantity | 1 |
Design |
---|
Chassis type | Ultra Micro Tower |
Optical drive type | No |
Performance |
---|
Remote administration | iLO 5 ASIC |
Operating system installed | No |
Compatible operating systems | Microsoft Windows Server 2019: Essentials, Standard, Datacenter, Hyper-V
Microsoft Windows Server 2022: Essentials, Standard, Datacenter
Red Hat Enterprise Linux (RHEL): 8.4 (64 bit, includes KVM)
VMware vSphere: 7.0 U3 |
Software |
---|
Operating system installed | No |
Compatible operating systems | Microsoft Windows Server 2019: Essentials, Standard, Datacenter, Hyper-V
Microsoft Windows Server 2022: Essentials, Standard, Datacenter
Red Hat Enterprise Linux (RHEL): 8.4 (64 bit, includes KVM)
VMware vSphere: 7.0 U3 |
Processor special features |
---|
Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
Intel VT-x with Extended Page Tables (EPT) | Yes |
Intel Virtualization Technology (VT-x) | Yes |
Intel Trusted Execution Technology | No |
Intel Stable Image Platform Program (SIPP) | No |
Intel Software Guard Extensions (Intel SGX) | Yes |
Intel Clear Video Technology | Yes |
Intel 64 | Yes |
Enhanced Intel SpeedStep Technology | Yes |
CPU configuration (max) | 1 |
Power |
---|
Redundant power supply (RPS) support | No |
Power supply | 180 W |
Technical details |
---|
Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
Weight & dimensions |
---|
Width | 245 mm |
Weight | 4.23 kg |
Height | 118.9 mm |
Depth | 245 mm |
Other features |
---|
CPU configuration (max) | 1 |
