21K30032AU | Lenovo ThinkPad T14 AMD Ryzen™ 5 PRO 7540U Laptop 35.6

Design
Colour name	Thunder Black
Product type	Laptop
Product colour	Black
Form factor	Clamshell
Display
HD type	WUXGA
Display diagonal	35.6 cm (14")
Display resolution	1920 x 1200 pixels
Touchscreen	Yes
LED backlight	Yes
Display brightness	300 cd/m Â²
Panel type	IPS
Contrast ratio (typical)	700:1
Anti-glare screen	Yes
RGB colour space	NTSC
Colour gamut	45%
Native aspect ratio	16:10
Processor
Processor cache type	L3
Processor frequency	3.2 GHz
Processor family	AMD Ryzen™ 5 PRO
Processor model	7540U
Processor boost frequency	4.9 GHz
Processor cores	6
Processor cache	16 MB
Motherboard chipset	AMD SoC
Processor manufacturer	AMD
Memory
Internal memory	16 GB
Internal memory type	LPDDR5x-SDRAM
Memory clock speed	6400 MHz
Maximum internal memory	16 GB
Memory form factor	On-board
Memory channels	Dual-channel
Storage
SSD form factor	M.2
Optical drive type	No
Total storage capacity	512 GB
Storage media	SSD
Number of SSDs installed	1
SSD capacity	512 GB
SSD interface	PCI Express 4.0
Card reader integrated	No
Total SSDs capacity	512 GB
NVMe	Yes
Graphics
Discrete graphics card	No
On-board graphics card model	AMD Radeon 740M
Discrete graphics card model	Not available
On-board graphics card	Yes
On-board GPU manufacturer	AMD
Audio
Audio chip	Realtek ALC3287
Number of microphones	2
Audio system	Dolby Audio
Number of built-in speakers	2
Speaker power	2 W
Built-in microphone	Yes
Camera
Front camera	Yes
Front camera resolution	1920 x 1080 pixels
Privacy camera	Yes
Privacy type	Privacy shutter
Front camera HD type	Full HD
Infrared (IR) camera	Yes
Windows Hello	Yes
Optical drive
Optical drive type	No
Network
Mobile network connection	Yes
Mobile network generation	4G
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
WLAN controller model	Qualcomm NFA725A
Bluetooth	Yes
Wi-Fi standards	Wi-Fi 6E (802.11ax)
Ethernet LAN	Yes
Ethernet LAN data rates	1000,100 Mbit/s
Bluetooth version	5.1
WWAN	Installed
4G standard	LTE
Antenna type	2x2
WLAN controller manufacturer	Qualcomm
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	1
USB Type-C DisplayPort Alternate Mode	Yes
HDMI ports quantity	1
HDMI version	2.1
Ethernet LAN (RJ-45) ports	1
Combo headphone/mic port	Yes
USB Sleep-and-Charge ports	1
USB Sleep-and-Charge	Yes
USB Power Delivery	Yes
USB4 Gen 3x2 ports quantity	1
Performance
Motherboard chipset	AMD SoC
Keyboard
Pointing device	ThinkPad UltraNav
Keyboard layout	QWERTY
Numeric keypad	No
Spill-resistant keyboard	Yes
Keyboard backlit	Yes
Keyboard language	English
Software
Operating system installed	Windows 11 Pro
Operating system architecture	64-bit
Operating system language	English
Battery
Battery technology	Lithium Polymer (LiPo)
Battery capacity	52.5 Wh
Fast charging	Yes
Power
AC adapter power	65 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
Security
Cable lock slot	Yes
Cable lock slot type	Kensington
Fingerprint reader	Yes
Trusted Platform Module (TPM)	Yes
Password protection	Yes
Password protection type	Power on, SSD, Supervisor
Windows Hello	Yes
Smart card reader	No
Trusted Platform Module (TPM) version	2.0
Operational conditions
Operating temperature (T-T)	5 - 35  Â°C
Storage temperature (T-T)	5 - 43  Â°C
Operating relative humidity (H-H)	8 - 95%
Storage relative humidity (H-H)	5 - 95%
Maximum shipping altitude	3048 m
Certificates
Certification	MIL-STD-810H
Compliance certificates	RoHS
Sustainability
Sustainability certificates	ENERGY STAR, EPEAT Gold, ErP, TCO
Weight & dimensions
Weight	1.38 kg
Width	317.7 mm
Depth	226.9 mm
Height	17.9 mm
Technical details
Sustainability certificates	ENERGY STAR, EPEAT Gold, ErP, TCO
Compliance certificates	RoHS
Other features
WLAN controller model	Qualcomm NFA725A
Audio system	Dolby Audio
On-board graphics card	Yes
Maximum shipping altitude	3048 m
Anti-glare screen	Yes

---

LENOVO ThinkPad T14 14'' WUXGA IR webcam TOUCH AMD R5-7450U 16GB DDR5 512GB SSD WIN 11 PRO AMD Radeon 4G-LTE WIFI6E Fingerprint Thunderbolt Backlit 3yr OS 1.3kg

Technical Specification

Display 14' WUXGA (1920x1200) IPS 300nits Anti-glare, 45% NTSC, Touch

Touchscreen On-cell, 10-point Multi-touch

Processor AMD Ryzen™ 5 PRO 7540U (6C / 12T, 3.2 / 4.9GHz, 6MB L2 / 16MB L3)

Memory 16GB Soldered LPDDR5x-6400

Storage 512GB SSD M.2 2280 PCIe Â® 4.0x4 NVMe Â® Opal 2.0

Memory Slots Memory soldered to systemboard, no slots, dual-channel

Card Reader None

Operating System Windows Â® 11 Pro

Graphics Integrated AMD Radeon™ 740M Graphics

Standard Ports
1x USB 3.2 Gen 1
1x USB 3.2 Gen 1 (Always On)
1x USB-C Â® 3.2 Gen 2 (support data transfer, Power Delivery 3.0 and DisplayPort™ 1.4a)
1x USB4 Â® 40Gbps (support data transfer, Power Delivery 3.0 and DisplayPort™ 1.4a)
1x HDMI Â® 2.1, up to 4K/60Hz
1x Headphone / microphone combo jack (3.5mm)
1x Ethernet (RJ-45)

Fingerprint Reader Touch Style, Match-on-Chip, Integrated in Power Button

Ethernet 100/1000M (RJ-45)

WLAN + Bluetooth Qualcomm Â® Wi-Fi Â® 6E NFA725A, 11ax 2x2 + BT5.3

Battery Integrated 52.5Wh

Keyboard Backlit

Power Adapter 65W USB-C Â® (3-pin)

Dimensions (WxDxH) 317.7 x 226.9 x 17.9 mm

Weight 1.39 kg

Base Warranty 3Y Onsite + 1Y Premier
