All stock codes associated to this product
GWU62501, GWU625-01, 881317507600
Compact Wireless-N USB Adapter
GWU625
Description
The new IOGEAR Compact Wireless-N USB Adapter allows you to connect your laptop or desktop to any Wireless-N network in your home or office. The Wireless-N (IEEE 802.11n) USB 2.0 Adapter is the perfect solution for those users who want to upgrade older computers to the next generation of wireless technology.
Using dual antennas (1T2R) this product provides data rates up to 300Mbps and reduces Wi-Fidead zones in your wireless environment. This new standard supplies sufficient bandwidth for faster file transfer, music downloads, video streaming, on-line gaming & HD multi-media applications. In addition to the increased speed and coverage, you will be pleased to know that it is compatible with your existing 802.11b and 802.11g routers and access points. The unit also features aWPS (Wi-Fi Protected Setup) button. This button assures quick and secure network setup.
Enjoy improved range, speed and reliability today with the Compact Wireless-N USB Adapter from IOGEAR!
Features
- Add high-speed Wireless-N (802.11n) Internet access to any USB enabled computer
- 1T2R multiple radio technology improves effective throughput and range over existing 802.11 b/g products
- Compact and portable adapter plugs into your computers USB port
- Compatible Network Standards: IEEE 802.11n (up to 300Mbps*) IEEE 802.11g (up to 54Mbps*) IEEE 802.11b (up to 11Mbps*)
- Push-button Wi-Fi Protected Setup (WPS) simplifies secure and easy wireless configuration
- WEP,TKZP, AES, WPA and WPA2 hardware encryption schemes
- Frequency Band Modulation Method: QPSK / BPSK / 16-QAM / 64-QAM
- Supports Ad Hoc and Infrastructure modes
- Supports USB 2.0 with up to 300Mbps transfer rate; backward compatible to USB 1.1 and 1.2
- Compatible with Microsoft Windows, Mac or Linux OS
*Maximum performance derived from IEEE Standard 802.11 specifications. Actual performance may vary, including lower wireless network capacity, data throughput rate, range and coverage. Performance depends on many factors, conditions and variables, including wireless distance, volume of network traffic, network overhead, building materials and construction, operating system being used, interference and other adverse conditions.
Warranty: 3-YEAR
Function Diagram
Requirements
- OperatingSystem
- WindowsXP, Windows Vista, Windows 7
- Mac OS X v10.4 and above
- Linux Fedora 10 (Kernel: 2.6.27.5-117)
- Available USBport
- Wireless network
Package Content
- 1 x Wireless-N USB 2.0 Adapter
- 1 x Driver CD
- 1 x Quick Start Guide
- 1 x Warranty / Registration Card
Warning: Do NOT insert the included mini disc into any slot-loading optical drive.Severe damage to your computer may occur.
Specifications
| Function |
GWU625 |
| Power Consumption |
Transmit : < 380mA. ; Receive: < 250mA. |
| Operating Temperature |
0 ~ 50 celsius |
| Storage Temperature |
-10 ~ 70 celsius |
| USB Specification |
USB 2.0 |
| Humidity |
5 ~ 90% (non-condensing) |
| Transmission Power |
17 dBm |
| Frequency Band |
2.4GHz ~ 2.483GHz unlicensed ISM band |
| Modulation |
IEEE 802.11n: BPSK, QPSK, 16-QAM, 64-QAM |
| Data Rate |
IEEE 802.11n : 6, 9, 12, 18, 24, 36, 48, 54, 60, 90, 120, 180, 240, 270 and up to 300Mbps |
| Interface |
USB 2.0 |
| Security |
64-bit or 128-bit WEP/WPA TKIP |
| Management |
Windows-based Utility |
| Operating Range |
100 - 400m, depending on surrounding environment |
| Encryption |
64 bit / 128 bit WEP, TKIP, AES |
| Antenna Type |
On board chip antenna |
| Range |
Up to 320 ft |
| Chipset |
RTL8191SU |
| Dimensions |
GWU625 |
| POP Information |
| 10'' Peg Hook |
10 |
| 6'' Peg Hook |
6 |
| Unit Dimensions |
| Width |
2" |
| Height |
1" |
| Depth |
0.25" |
| Inner Pack |
| Width |
5" |
| Height |
9.5" |
| Depth |
5.5" |
| Inner Pack Qty. |
6 |
| Unit Package Dimensions |
| Width |
5" |
| Height |
7.75" |
| Depth |
1" |
| Master Carton |
| Width |
6" |
| Height |
11.5" |
| Depth |
12.5" |
| Master Carton Qty. |
12 |
| Weight |
| Master Carton Wt. |
3.25 lb |
| Inner Pack Wt. |
1.25 lb |
| Unit Pack Wt. |
0.15 lb |
| Unit Wt. |
0.30 oz |
