 The VS-2004L VioStor NVR is the 2-bay network surveillance system for home and SOHO security applications. The Linux-based system supports 4-channel H.264, MPEG-4, and M-JPEG recording from ONVIF-compliant IP cameras and surveillance devices from AXIS, ACTi, A-MTK, Arecont Vision, AVTECH, Brickcom, Canon, Cisco, CNB, DIGITUS, D-Link, EDIMAX, ELMO, EtroVision, GANZ, Honeywell, iPUX, IPX, IQeye, LevelOne, Linksys, Messoa, MOBOTIX, NAKAYO, Panasonic BB/BL/i-Pro, Pelco, SANYO, SHANY, SONY, TOA, TOSHIBA, TRENDnet, Videosec, VIOSECURE, VIVOTEK, and Y-CAM.
The unique multi-server monitoring feature of the VioStor NVR allows monitoring of up to 128 IP cameras from multiple QNAP NVR servers at the same time. No extra software is required. Instant alarm icon will be shown and the alarm channel will be highlighted to inform the administrator immediately if an event occurs.
The VioStor NVR supports diversified recording features, such as scheduled recording, alarm recording by multiple alarm events, alarm recording schedule, and pre-alarm and post-alarm recordings. Advanced event management is provided for the administrator to define the handling options when events or alarms are triggered. The VioStor NVR also offers enhanced video search by intelligent video analytics (IVA), such as motion detection, foreign object, missing object, out of focus, and camera occlusion. Moreover, you can use the video surveillance application "VMobile" to monitor the IP cameras with your iPad, iPhone, iPod touch, and Windows PDA phones anytime, anywhere.
Powerful Features of VioStor NVR (Network Video Recorder):
- Real-time monitoring and recording (video/audio) from multiple IP cameras (up to 4 channels)
- High quality H.264, MPEG-4, and M-JPEG recording (depending on the camera models)
- Complete recording features
- Multi-server monitoring (up to 128 channels)
- Dual display mode
- Video search by date and time, timeline, and event
- Intelligent video analytics (IVA)
- Multi-view playback from multiple NVR servers
- Digital watermarking
- Advanced event management
- Real-time SMS and email alert
- Live monitoring on iPad, iPhone, iPod Touch and Windows PDA phone by VMobile
- Trouble-free installation
- Linux-embedded, highly reliable standalone NVR
- Advanced RAID management
- Online RAID capacity expansion and online RAID level migration
- UPS Support for 24/7 service
- Intelligent auto power on after power recovery
- Energy-saving design (only 7W in operation)
Surveillance Features
Complete Recording Functions
High Quality H.264, MPEG-4, and M-JPEG Recording (depending on the camera models)
All-in-one Recording Functions
 Continuous/manual/scheduled recording*- Alarm recording (by multiple events), alarm recording schedule*
- Pre-alarm and post-alarm recording
- Audio recording
* You can set different recording schedules for different cameras.
 Generic IP Cameras Support
VioStor NVR provides an interface for the users to enter the JPEG CGI command of their IP cameras to retrieve the video and audio data from the IP cameras.
Network Surveillance by Web-based Interface (IE Browser)
Real-time Remote Monitoring
Multi-server Monitoring
You can connect to one VioStor NVR and monitor up to 128 channels from other VioStor NVR servers over LAN or WAN by an IE browser.
Diversified Remote Monitoring Modes
- 1/4/6/8/9/10/12/16/20/25/36/42-channel and sequential display mode
- Exclusive Picture-in-Picture mode
- Multi-display mode
 Smart Control of PTZ & Speed Dome Cameras
You can adjust the PTZ cameras directly by the web user interface of VioStor NVR.
 Preset Position Control and Auto Cruising
You can view the preset positions of an IP camera by clicking the corresponding number buttons on the monitoring page. You can also choose the preset positions and configure the time interval on the PTZ cameras for periodic monitoring.
 Instant Event Notification
When alarm recording is enabled and an event occurs, an alarm icon is shown instantly on the monitoring page. You can click the icon to view the alert details.
 Digital Zoom
You can zoom in or zoom out the video image on the monitoring and playback interfaces.
 E-map
VioStor NVR provides exclusive E-map function for users to upload the pictures of the monitoring locations.
 Remote Video Playback
Multi-view Playback
You can use the multi-view playback feature to divide a video equally into multiple sessions for playback in a multi-view window, or play the videos of multiple IP cameras in the multi-view window simultaneously.
Video Search by Date and Time, Timeline, Event, Intelligent Video Analytics (IVA)
VioStor NVR supports quick video search by date and time, timeline, event, and intelligent video analytics (IVA), including motion detection, foreign object, missing object, out of focus, and camera occlusion.
 How to use intelligent video analytics on playback
 Digital Watermarking
VioStor NVR supports digital watermarking to protect the exported videos and snapshots from unauthorized modification. You can use the Watermark Proof utility to verify whether or not the videos and snapshots are original.
Event Management
 Advanced Event Management
VioStor NVR supports various event handling options for different kinds of events.
- Events: Motion detection, alarm input, connection failure, recording failure, and user-defined event.
- Actions: Video recording, email alert, SMS alert, buzzer, PTZ camera control, alarm output, and user-defined action.
 Real-time SMS and Email Alert
You can configure the SMTP server and SMSC server settings on the NVR in order to receive instant system warning or error messages by email and/or SMS.
Convenient Backup Solution
Scheduled Remote Replication
VioStor NVR supports scheduled remote replication for secure data backup to a remote QNAP NAS on the local network.
One-Touch-Auto-Video-Backup
You can configure the one-touch-auto-video-backup button on the front of the NVR to copy the data from the NVR to an external storage device when the button is pressed.
Security Control
Authority Management
You can create multiple users on VioStor NVR. The users created on the NVR can be assigned to different user groups (administrator/system manager/user) with different rights of monitoring, playback, PTZ control, and audio monitoring.
 Auto Logoff
VioStor NVR supports automatic user logoff from idling configuration pages. The administrator can set the timeout period to log off the users when the idling time has reached.
 Host Access Control
You can specify the host or IP connections to be allowed and denied to access NVR.
 On-line User List
You can view the record of users currently logged on and previously logged on to the NVR.
 Detailed Event Logs
VioStor NVR provides detailed event logs of system warning, hard disk error, network disconnection, UPS status, users' networking services and recordings access record.
High Reliability and Smart Features
Advanced RAID Management
VioStor NVR supports RAID 0, 1, single, and JBOD disk configurations.
Online RAID Capacity Expansion and Online RAID Level Migration
 Online RAID Capacity Expansion
The storage capacity of a RAID configuration can be expanded by replacing the hard drives with larger ones. All the data will be kept and seamlessly moved to the newly installed hard drives. There is no need to turn off the server during the process. Online RAID Level Migration
You can upgrade the disk configuration to higher RAID level with the data retained without turning off the server.
 S.M.A.R.T. & Advanced HDD Health Scanning (HHS)
S.M.A.R.T. (Self-Monitoring Analysis and Reporting Technology) helps you monitor the hard disk drives status. VioStor NVR supports HHS (HDD Health Scan) for disk checking and bad blocks scanning.
 Automatic System Startup after Power Recovery
VioStor NVR supports automatic power-on when power resumes after power outage.
 UPS Support for 24/7 Service
VioStor NVR supports APC, CyberPower, and MGE UPS devices to provide continuous services 24/7 against unexpected power outage.
Network Services
Built-in DDNS Service
VioStor NVR supports dynamic DNS (DDNS). You can register a unique domain name from a DDNS service provider and assign it to your NVR.
Built-in NTP Server
You can enable this feature to allow the connected IP cameras to synchronize their date and time settings with the NVR.
 Convenient Data Access
The video data of VioStor NVR can be accessed by the following protocols with proper access rights:
- Network Places (SMB/CIFS)
- Web file management (HTTP)
- FTP server
Easy Configuration and Management
System Setup in Simple Steps
You can set up the NVR easily in simple steps by the local display and web-based interface.
Web-based User Interface
All system configurations, monitoring, and playback can be finished by the web-based interface.
Smart Search of IP Camera for Quick Settings
QNAP provides an intelligent software utility Finder for quick IP camera search and system settings.
Excellent Hardware Design
Green NVR Solution: Energy-Saving Linux-embedded System
VioStor NVR is a Linux-embedded system which is more power-saving and less vulnerable to virus attack compared to PC-based surveillance solutions.
Up to 4TB Storage Capacity for Long-term Recording
VioStor NVR supports maximum 2 high-speed SATA hard drives for recording large amount of video data in a long period of time.
|
