Overview
Something of a powerhouse when it comes to Power-over-Ethernet switches, this
compact beauty offers PoE to 802.3af/at standard across all eight Gigabit
Ethernet ports, at up to 30 Watts per port with a power budget total of 140
Watts. Which, put simply, means you can power devices such as access points, IP
phones and video surveillance cameras simply by plugging them in with an
Ethernet cable no additional power required.
PoE
The DGS-1008MP features 8 x 10/100/1000BASE-T ports that support the IEEE
802.3at PoE+ protocol. Each of the 8 PoE+ ports can supply up to 30 watts with a
total PoE power budget of 140 watts. PoE is especially suitable for devices that
are far from power outlets or when you want to minimise the clutter of extra
cables.
Superior Performance
No configuration is required and installation is quick and easy. Support for
Auto MDI/MDI-X on all ports eliminates the need for crossover cables when
connecting to another switch. Auto- Negotiation on each port senses the link
speed of a network device (10, 100 or 1000 Mbps) and intelligently adjusts for
compatibility and optimal performance. The switch has been designed without fans
ensuring silent operation wherever it is installed. With wire-speed filtering
and store-and-forward switching, the DGS-1008MP maximises network performance
while minimising the transmission of bad network packets.
Energy Saving
DGS-1008MP switches feature both D-Link Green 3.0 Technology and IEEE802.3az
Energy Efficient Ethernet (EEE) to cut operating costs without sacrificing
operational performance or functionality. With D-Link Green technology, the
switches constantly monitor the link status and network utilisation of every
port. The switches also automatically detect cable length and can reduce
transmission power usage for shorter cables. By pairing EEE capable devices with
DGS-1008MP switches organizations can drastically reduce power consumption by
automatically putting ports into a sleep mode when not being used.
Speciifcations
|
General |
|
|
Size |
11-inch Desktop/Rackmount size, 1U height |
|
|
|
Number of Ports |
8 10/100/1000 Mbps Ports |
|
|
|
Port Standards & Functions |
IEEE 802.3i 10BASE-T Ethernet |
|
IEEE 802.3u 100BASE-TX Fast Ethernet |
|
IEEE 802.3ab 1000BASE-T Gigabit Ethernet |
|
IEEE 802.3at Power over Ethernet |
|
IEEE 802.3az Energy Efficient Ethernet |
|
IEEE 802.3x Flow Control supports half/full duplex
mode |
|
ANSI/IEEE 802.3 NWay auto-negotiation |
|
|
|
Switching Capacity |
16 Gbps switching fabric |
|
|
|
Media Interface Exchange |
Auto MDI/MDI-X |
|
|
|
Transmission Method |
Store-and-forward |
|
|
|
MAC Address Table |
8K entries per device |
|
|
|
Packet Buffer Memory |
128 KB per device |
|
|
|
Packet Filtering / Forwarding Rates |
|
|
Ethernet |
14,880 pps per port |
|
Fast Ethernet |
148,800 pps per port |
|
Gigabit Ethernet |
1,488,000 pps per port |
|
|
|
Data Transfer Rates |
Ethernet |
|
10 Mbps (half duplex) |
|
20 Mbps (full duplex) |
|
Fast Ethernet |
|
100 Mbps (half duplex) |
|
200 Mbps (full duplex) |
|
Gigabit Ethernet |
|
2000 Mbps (full duplex) |
|
|
|
Network Cables |
|
|
10BASE-T |
UTP CAT 3/4/5/5e (100 m max.) |
|
EIA/TIA-586 100-ohm STP (100 max.) |
|
100BASE-TX |
|
UTP CAT 5/5e (100 m max.) |
|
EIA/TIA-568 100-ohm STP (100 max.) |
|
1000BASE-T |
|
UTP CAT 5/5e(100 m max.) |
|
EIA/TIA-568 100-ohm STP(100 max.) |
|
|
|
Physical |
|
|
LED Indicators |
|
|
Per port |
Activity / Link and Speed |
|
Per port |
Power / Status |
|
PoE Max 1 |
Ports 1-4 |
|
PoE Max 2 |
Ports 5-8 |
|
|
|
Dimensions |
280 mm x 180 mm x 44 mm (11.02 x 7.08 x 1.73
inches) |
|
|
|
Power Input |
|
|
AC Input |
100 to 240 V AC, 50/60 Hz |
|
|
|
Maximum PoE Budget |
140 watts |
|
|
|
Power Consumption |
13.5 watts (PoE off) |
|
151 watts (PoE on) |
|
PoE up to 30 watts per port |
|
|
|
Temperature |
|
|
Operating |
0 to 40 °C (32 to 104 °F) |
|
Storage |
-10 to 70 °C (14 to 158 °F) |
|
|
|
Humidity |
|
|
Operating |
0% to 95% RH non-condensing |
|
Storage |
5% to 95% RH non-condensing |
|
|
|
EMI |
CE Class A |
|
FCC Class A |
|
VCCI Class A |
|
CCC Class A |
|
BSMI Class A |
|
|
|
Safety |
cUL |
|
CB |
|
LVD |
|
CCC |
|
BSMI |
