TP-Link Archer MR400 AC1350 Wireless Dual-Band 4G LTE Router
Features
- Shares your 4G LTE network with multiple Wi-Fi devices and enjoy download
speeds of up to 150Mbps
- Powerful, integrated antennas provide stable wireless connections and
better coverage
- Requires no configuration, just insert a SIM card and turn it on to enjoy
a fast wireless connection
- Creates simultaneous dual band Wi-Fi networks, with maximum speeds of up
to 450Mbps on the 2.4GHz band and 867Mbps on the 5GHz band
- Offers options and flexibility with the LAN/WAN port, allowing you to
choose your connection type
Offers options and flexibility with the LAN/WAN port, allowing you to
choose your connection type
AC1350 Wireless Dual Band 4G LTE Router Archer MR400
Share Your 4G LTE Network
Take full advantage of your cutting-edge 4G LTE network with the Archer
MR400, which can achieve download speeds of up to 150Mbps. The Archer MR400
allows you to share your 4G LTE network with multiple Wi-Fi devices so you can
enjoy uninterrupted HD movies, rapid file downloads, and video chats that won't
freeze up.
Great Coverage and Dual Band Wi-Fi
The 4G LTE router creates a simultaneous dual band Wi-Fi network that can
deliver data at speeds of up to 1350Mbps. The two distinct wireless networks,
utilizing the 2.4GHz and 5GHz bands, provide optimized performance and minimize
signal interference. The incorporation of advanced antennas and the latest
wireless technology allows you to enjoy stable connections and incredible
coverage.
Got SIM Card? Then Plug and Play!
With an integrated 4G LTE modem and a built-in SIM card slot, all you need to
do insert a SIM card and turn on the Archer MR400. Enjoying fast, stable Wi-Fi
on a 4G LTE network has never been easier.
Wi-Fi Where You Need It
The Archer MR400 offers unmatched convenience and versatility. The ability to
quickly establish powerful wireless networks can be tremendously important. The
Archer MR400 is the perfect solution whether you're at home or working in a
remote location. Just plug it in to boost on-site productivity and stay
connected in a diverse range of environments. From the exhibition center to the
RV, the Archer MR400 has you covered.
Easy Setup and Management
Set up the Archer MR400 in minutes thanks to its intuitive web interface and
the powerful Tether app. Manage network settings, including Parental Controls
and Access Control, from any Android or iOS device. Control your home network
whenever and wherever you are.
Specifications
|
HARDWARE FEATURES |
|
|
Interface |
3 10/100Mbps LAN Ports, 1 10/100Mbps LAN/WAN Port, 1 SIM Card
Slot |
|
Button |
WPS/Reset Button, Wireless On/Off Button, Power On/Off
Button |
|
Antenna |
3 Internal Wi-Fi Antennas, |
|
|
2 Detachable External 4G LTE Antennas |
|
External Power Supply |
12V/1.5A |
|
Dimensions ( W x D x H ) |
7.95 x 5.55 x 1.32 in. (202 x 141 x 33.6 mm) |
|
|
|
|
WIRELESS FEATURES |
|
|
Wireless Standards |
IEEE 802.11ac/n/a 5GHz, IEEE 802.11b/g/n 2.4GHz |
|
Frequency |
2.4GHz and 5GHz |
|
Signal Rate |
450Mbps at 2.4GHz, 867Mbps at 5GHz |
|
Reception Sensitivity |
5GHz: 11a 54M: -74dBm |
|
|
11ac HT20: -67dBm |
|
|
11ac HT40: -64dBm |
|
|
11ac HT80 : -60dBm |
|
|
11n HT20: -71dBm |
|
|
11n HT40: -70dBm |
|
|
|
|
|
2.4G: 11g 54M: -76dBm |
|
|
11n HT20: -73dBm |
|
|
11n HT40: -67dBm |
|
Transmit Power |
CE: <20dBm(2.4GHz), <23dBm(5GHz) |
|
Wireless Functions |
Enable/Disable Wireless Radio, WMM,Wireless
Statistics |
|
Wireless Security |
64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK
encryptions |
|
Network Type |
4G: FDD-LTE B1/B3/B7/B8/B20
(2100/1800/2600/900/800MHz) |
|
|
TDD-LTE B38/B39/B40/B41 (2600/1900/2300/2500MHz) |
|
|
3G: DC-HSPA+/HSPA+/HSPA/UMTS B1/B8 (2100/900MHz) |
|
|
2G: EDGE/GPRS/GSM Quad Band (850/900/1800/1900MHz) |
|
|
|
|
SOFTWARE FEATURES |
|
|
Quality of Service |
Traffic Control(IP QoS) |
|
Operating Modes |
3G/4G Router, Wireless Router |
|
WAN Type |
Dynamic IP/Static IP/PPPoE/PPTP(Dual Access)/L2TP(Dual
Access) |
|
Management |
Access Control, Local Management, Remote
Management |
|
DHCP |
Server, Client, DHCP Client List, Address
Reservation |
|
Port Forwarding |
Virtual Server, Port Triggering, UPnP, DMZ |
|
Dynamic DNS |
DynDns, NO-IP |
|
VPN Pass-Through |
PPTP, L2TP, IPSec |
|
Access Control |
Parental Control, Local Management Control, Host
List, |
|
|
Access Schedule, Rule Management |
|
Firewall Security |
DoS, SPI Firewall, IP Address Filter/Domain Filter,
|
|
|
IP and MAC Address Binding |
|
Protocols |
Supports IPv4 and IPv6 |
|
Guest Network |
2.4GHz guest network x 1, 5GHz guest network x 1 |
|
IPSec VPN |
Supports up to 10 IPSec VPN tunnels |
|
|
|
|
OTHERS |
|
|
Certification |
CE, RoHS |
|
Package Contents |
AC1350 Wireless Dual Band 4G LTE Router, Archer
MR400 |
|
|
RJ45 Ethernet Cable |
|
|
Power Adapter |
|
|
Quick Installation Guide |
|
|
Micro to Standard SIM Card Adapter |
|
|
Nano to Standard SIM Card Adapter |
|
System Requirements |
Microsoft Windows 98SE, NT, 2000, XP, Vistaâ„¢ or Windows 7, 8, 8.1, MAC
OS, NetWare, UNIX or Linux |
|
|
Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0 browers or
higher,or other Java-enabled browsers |
|
|
SIM Card |
|
Environment |
Operating Temperature: 0℃~40℃ (32℉ ~104℉) |
|
|
Storage Temperature: -40℃~70℃ (-40℉ ~158℉) |
|
|
Operating Humidity: 10%~90% non-condensing |
|
|
Storage Humidity: 5%~90%
non-condensing |
