All stock codes associated to this product
MZV7E250BW, MZ-V7E250BW, 06SS970E250GBMP, 06SS-970E-250GB-MP, 8801643205386, SSD-SAM-V7E250BW, SSD-SAM-V7E250BW
Samsung 250GB NVMe M.2 SSD - M.2 2280, V-NAND 3-bit MLC, PCIe Gen
3.0x4, NVMe 1.3 - 970 EVO Series
The SSD that goes further
Accelerate into next-gen computing. The Samsung 970 EVO delivers breakthrough
speeds, best-in-class reliability, and a broad range of capacity options up to
2TB*. The latest V-NAND, new Phoenix controller, and Intelligent TurboWrite
technology enhance high-end gaming and 4K & 3D graphic editing.
*1GB=1,000,000,000 bytes by IDEMA. A certain portion of capacity may be used
for system file and maintenance use, so the actual capacity may differ from what
is indicated on the product label.
Next level SSD speed
Feel the NVMe difference. The 970 EVO transforms high-end gaming and
streamlines graphic intensive workflows with the new Phoenix controller and
Intelligent TurboWrite technology. Get stunning sequential read/write speeds of
3,500/2,500 MB/s*, up to 32% faster writes than the previous generation.
* Performance may vary based on SSDs firmware version, system hardware and
configuration. Performance measurements based on IOmeter 1.1.0. Write
performance measurements are based on Intelligent TurboWrite technology. * Test
system configuration: Intel Core i7-7700K CPU @4.2GHz, DDR4 2400MHz 32GB,
OS-Windows 10 Built 10240, ChipsetASUS PRIME Z270-A* The sequential write
performances after TurboWrite region are: 300 MB/s(250GB), 600 MB/s(500GB),
1,200 MB/s(1TB) and 1,250 MB/s(2TB). For more information on the TurboWrite,
please visit www.samsungssd.com.
Design Flexibility
The next advancement in NVMe SSD. The 970 EVO fits up to 2TB onto the compact
M.2 (2280) form factor, greatly expanding storage capacity and saving space for
other components. Samsung†s innovative technology empowers you with the capacity
to do more and accomplish more.
Exceptional Endurance
The new standard in sustainable performance. Get up to 1,200 TBW* with a
5-year limited warranty, achieving 50 percent higher than the previous
generation. The 970 EVO provides exceptional endurance powered by the latest
V-NAND technology and Samsung’s quality.
* TBW: Terabytes Written* Warrantied TBW for 970 EVO: 150 TBW for 250GB
model, 300 TBW for 500GB model, 600 TBW for 1TB model, 1,200 TBW for 2TB model.*
5-years or TBW, whichever comes first. For more information on the warranty,
please find the enclosed warranty statement in the package.
Unparalleled Reliability
Achieve a new level of drive confidence. Samsung’s advanced nickel-coated
controller and heat spreader on the 970 EVO enable superior heat dissipation.
The Dynamic Thermal Guard automatically monitors and maintains optimal operating
temperatures to minimize performance drops.
Samsung Magician
Advanced drive management made simple. The Samsung Magician software will
help you keep an eye on your drive. A suite of user-friendly tools helps keep
your drive up to date, monitor drive health and speed, and even boost
performance.
Specifications
- Application Client PCs
- Capacity 250GB (1GB=1 Billion byte by IDEMA) * Actual usable capacity may
be less (due to formatting, partitioning, operating system, applications or
otherwise)
- Form Factor M.2 (2280)
- Interface PCIe Gen 3.0 x4, NVMe 1.3
- Dimension (WxHxD) 80.15 x 22.15 x 2.38 (mm)
- Weight Max 8.0 g Weight
- Storage Memory Samsung V-NAND 3-bit MLC
- Controller Samsung Phoenix Controller
- Cache Memory Samsung 512MB Low Power DDR4 SDRAM
Special Feature
- TRIM Support Supported
- S.M.A.R.T Support Supported
- GC (Garbage Collection) Auto Garbage Collection Algorithm
- Encryption Support AES 256-bit Encryption (Class 0)TCG/Opal IEEE1667
(Encrypted drive)
- WWN Support Not supported
- Device Sleep Mode Support Yes
Performance
- Sequential Read Up to 3,400 MB/s * Performance may vary based on system
hardware & configuration
- Sequential Write Up to 1,500 MB/s * Performance may vary based on system
hardware & configuration
- Random Read (4KB, QD32) Up to 200,000 IOPS * Performance may vary based on
system hardware & configuration
- Random Write (4KB, QD32) Up to 350,000 IOPS * Performance may vary based
on system hardware & configuration
- Random Read (4KB, QD1) Up to 15,000 IOPS * Performance may vary based on
system hardware & configuration
- Random Write (4KB, QD1) Up to 50,000 IOPS * Performance may vary based on
system hardware & configuration
Environment
- Average Power Consumption (system level) * Average: 5.4 W * Maximum: 9 W
(Burst mode) * Actual power consumption may vary depending on system hardware
& configuration
- Power consumption (Idle) Max. 30 mW * Actual power consumption may vary
depending on system hardware & configuration
- Allowable Voltage 3.3 V5 % Allowable voltage
- Reliability (MTBF) 1.5 Million Hours Reliability (MTBF)
- Operating Temperature 0 - 70 Operating Temperature
- Shock 1,500 G & 0.5 ms (Half sine)
Accessories
- Installation Kit Not Available
Software
- Management SW Magician Software for SSD management
Warranty 5-Year Limited Warranty or 150 TBW Limited Warranty
