Description |
Specification |
|
Safety
Certifications |
UL/CSA
60950-1 |
|
EN
60950-1 |
|
CB to IEC 60950-1 (with
country deviations) |
|
NOM to NOM-019-SCF1
(through partners and distributors) |
|
CE
Marking |
|
Hazard
Location |
ANSI/ISA 12.12.01
(Class1, Div2 A-D)* |
|
EN 60079-0, -15 ATEX
Certificate (Class 1, Zone2 A-D)* |
|
*Cabinet
enclosure required |
|
EMC Emissions and
Immunity Compliance |
FCC 47 CFR Part 15
Class A |
|
EN 55022A Class
A |
|
VCCI Class
A |
|
RoHS
compliance |
|
AS/NZS CISPR 22 Class
A, AS/NZS CISPR 24 |
|
CISPR11 Class A,
CISPR22 Class A |
|
ICES 003 Class
A |
|
KCC
-Korea |
|
CE
Marking |
|
C-Tick
(Australia) |
|
Russia
certification |
|
Brazil
certification |
|
IEC/EN/EN61000-4-2
(Electro Static Discharge), 15kV air/8kV contact |
|
IEC/EN 61000-4-3
(Radiated Immunity, 10 and 20 V/m) |
|
IEC/EN 61000-4-4 (Fast
Transients - 4kV power line, 4kV data line) |
|
IEC/EN 61000-4-5 (Surge
2 kV/1 kV) |
|
IEC/EN 61000-4-6
(Conducted Immunity, 10 V/emf) |
|
IEC/EN 61000-4-8 (Power
Frequency Magnetic Field Immunity) |
|
IEC/EN 61000-4-9 (Pulse
Magnetic Field Immunity) |
|
IEC/EN 61000-4-10
(Oscillatory Magnetic Field Immunity) |
|
IEC/EN 61000-4-11 (AC
power Voltage Immunity) |
|
IEC/EN 61000-4-29
(Voltage Dips Immunity) |
|
IEC/EN 61000-6-1
(Immunity for Light Industrial Environments) |
|
IEC/EN 61000-6-2
(Immunity for Industrial Environments) |
|
IEC/EN 61000-6-4 Class
A |
|
EN
61326 |
|
Shock and
Vibration |
IEC 60068-2-27
(Operational Shock: 30G 11ms, half sine) |
|
IEC 60068-2-27
(Non-Operational Shock 55-70G, trapezoidal) |
|
IEC 60068-2-6, IEC
60068-2-64, EN 61373 (Operational Vibration) |
|
IEC 60068-2-6, IEC
60068-2-64, EN 61373 (Non-operational Vibration) |
|
Industry
Standards |
UL508 |
|
CSA C22.2 No.
142 |
|
EN 61131-2 (EMC/EMI,
environmental, mechanical) |
|
Protective coating
(specific models only) |
|
Marine
DnV |
|
Substation KEMA (IEEE
1613, IEC 61850-3) |
|
Railway EN 50155
(EMI/EMC, environmental, mechanical) |
|
EN50121-3-2 |
|
EN50121-4 |
|
NEMA TS-2 (EMC,
environmental, mechanical) |
|
ABB Industrial IT
certification |
|
IP30 |
|
ODVA Industrial
Ethernet/IP support |
|
PROFINETv2.3
support |
|
Corrosive
Testing |
ISO-12944-6 |
|
IEC-60068-2-60 |
|
Humidity |
IEC 60068-2-52 (salt
fog mist, test Kb) marine environments |
|
IEC 60068
-2-3 |
|
IEC
60068-2-30 |
|
Relative humidity: 5%
to 95% non-condensing |
|
Operating
Temperature |
-40C to +70C (vented
enclosure - 40 LFM Air Flow) |
|
-40C to +60C (sealed
enclosure 0 LFM Air Flow) |
|
-34C to +75C (fan or
blower-equipped enclosure 200 LFM Air Flow) |
|
-40C to +85C (IEC
60068-2-2 Environmental Type Testing 16 hours) |
|
Operational altitude:
Up to 15,000 ft |
|
Storage
Temperature |
-40 C to +85 C (storage
temperature) |
|
IEC
60068-2-14 |
|
Storage altitude: Up to
15,000 ft |
|
Mean Time Between
Failure (MTBF) |
Mean time between
failure: 374,052 hours (42.7 years) |
|
Warranty |
Five-year limited
warranty on all IE-2000 HW PIDs and all IE Power Supplies defined in table
4 above. See link below for details on
warranty |
