Physical |
|
|
Dimensions
(H x W x D, mm) |
203x44.45x482.6 |
|
Mounting
Style |
Button
mounting on rear and sides, variable mounting bracket. 1U/2U form factor
ePDUs can be mounted horizontaly, vertically, or under a
surface. |
|
Form
factor |
1U |
|
|
|
|
Input |
|
|
Max
kW |
2 |
|
Plug |
(1)
IEC-320-C14 |
|
|
 |
|
|
|
|
Cable
Length (m) |
3 |
|
Voltage |
230V |
|
Current |
10 |
|
Phase |
Single-phase |
|
Frequency |
50Hz |
|
|
|
|
Output |
|
|
Grip
cable retention |
Yes |
|
Outlets |
(8)
IEC-320-C13 |
|
|
 |
|
|
|
|
Outlet
Control |
No |
|
|
|
|
Protection
& Filtering |
|
|
Spike/Surge
Suppression |
None |
|
EMI/RFI
Filter |
None |
|
|
|
|
Control
& Interface |
|
|
Daisy
Chain |
8
ePDUs |
|
Operating
Temperature |
60
Degrees C |
|
Hot
Swap Network and Control |
Yes |
|
Communication
and Protocols |
HTTP,
HTTPS, SSL, Telnet, FTP, SNMP, SMTP, DNS, DHCP, LDAP,
RADIUS |
|
Optional
Temperature and Humidity probe |
EMP001 |
|
Serial
Interface |
Yes |
|
Environmental
Interface |
Yes |
|
Ethernet
Interface |
Yes |
|
Voltage
Monitoring |
Yes |
|
|
|
|
Metering
and Switching |
|
|
Metering |
Input,
Branch, Phase |
|
Metering
Characteristics |
V,
W, A and kWhr, Active power, Apparent Power, Peak
Power |
|
Metering
Accuracy |
IEC
Class 1 Billing grade Accuracy |
|
|
|
|
Environmental
& Approval Standards |
|
|
Approvals |
CB,
CE, EN 60950-1:2006/A11:2009/A1:2010/A12:2011 Safety - Part 1: General
Requirements, IEC 60950-1(ed.2), IEC 60950-1(ed.2);am1 EN 55022:2010 Radio
Disturbance characteristics - Limits and methods of measurement. EN
55024:2010 Immunity characteristics - Limits and methods of
measurement. |
|
Electromagnetic
compatibility |
EN
61000-6-2:2005 Part 6-2: Generic standards - Immunity for industrial
environments EN 61000-6-4:2007+A1:2011 Part 6-4: Generic standards -
Emission standard for industrial environments |
|
Environmental |
RoHS
Directive – 2011/65/EU, EN 50581 : 2012, REACH Regulation (CE No.
1907/2006), WEEE directive 2012/19/EU, PEP ecopassport (Basic ePDUs)
Packaging: 100% recycled, 100% recyclable: no plastic, no metal, no
foam. |
|
Manufacturing
Plant |
ISO
9001:2008 / ISO 14001:2004 |
|
|
|
|
Warranty |
|
|
Standard
warranty |
2
years |
