All stock codes associated to this product
MR70X, NWMSMR70X, NWMS-MR70X, MR70X , 5243279, II345883, 6957939000509
TP-Link MR70X AX1800 Dual-Band WiFi 6 Router
Overview
- Next-Gen WiFi 6 Speeds Optimal WiFi 6 speeds reaching up to 1.8 Gbps (1201
Mbps on the 5 GHz band and 574 Mbps on the 2.4 GHz band)
- 4x More Capacity OFDMA and MU-MIMO allow simultaneous data transmission to
and from several devices, improving overall network efficiency
- Broader, Stronger Coverage 4x multi-directional high-gain antennas with
Beamforming boost stable connections throughout your home for strong WiFi
signals in every corner
- Overall Security Protection The latest WPA3 provides improved WiFi
security
- Gigabit Wired Connections Make full use of your internet access and
transfer data at dizzying speeds for peak performance
- Eco-Friendly Power Saving Target Wake Time (TWT) reduces power consumption
for your mobile and IoT devices during data transmissions
- Less WiFi Interference Minimizes the interference from neighboring signals
to improve transmission efficiency with BSS color
- Smart Connect Intelligently chooses the best available band for each
device
- Access Point Mode Extends a wired network and makes it wireless
Specifications
|
Wireless |
|
|
Wireless
Standards |
Compatible
with 802.11ax/ac/a/b/g/n Wi-Fi standards |
|
WiFi
Speeds |
1201
Mbps (5 GHz) + 574 Mbps (2.4 GHz) |
|
Reception
Sensitivity |
11g
6Mbps: -96dBm |
|
11g
54Mbps: -78dBm |
|
11n
HT40 MCS7:-74dBm |
|
11n
HT20 MCS7:-77dBm |
|
11a
6Mbps:-94dBm |
|
11a
54Mbps:-76dBm |
|
11ac
VHT20 MCS8:-71dBm |
|
11ac
VHT40 MCS8:-68dBm |
|
11ac
VHT80 MCS8:-65dBm |
|
Transmission
Power |
2.4
GHz < 20dBm (EIRP) |
|
5
GHz < 23dBm (EIRP) |
|
Wireless
Security |
WPA-PSK
/ WPA2-PSK/ WPA3 wireless encryption |
|
Wireless
Functions |
Enable/Disable
Wireless Radio, WMM |
|
Software |
|
|
WAN
Type |
Dynamic
IP/Static IP/PPPoE/L2TP/PPTP |
|
Management |
Access
Control |
|
Local
Management |
|
Remote
Management |
|
DHCP |
Server,
DHCP Client List |
|
NAT
Forwarding |
Port
Forwarding, Port Triggering, UPnP, DMZ |
|
Firewall
Security |
SPI
Firewall, IP and MAC Address Binding |
|
Guest
Network |
2.4
GHz Guest Network, 5 GHz Guest Network |
|
VPN
Passthrough |
OpenVPN,
PPTP supported |
|
Hardware |
|
|
Dimensions |
8.2
x 6.8 x 1.6 in (208.8 x 171.6 x 41.7 mm) |
|
Interfaces |
1x
Gigabit WAN Port + 3x Gigabit LAN Ports |
|
Button |
Reset/WPS
Button |
|
Antenna
Type |
4x
5 dBi Fixed Omni-Directional Antennas |
|
Others |
|
|
Package
Contents |
AX1800
Wi-Fi 6 Router MR70X |
|
Power
Adapter |
|
Quick
Installation Guide |
|
RJ45
Ethernet Cable |
|
Environment |
Operating
Temperature: 0C~40C (32F~104F) |
|
Operating
Humidity: 10%~90% Non-Condensing |
|
Storage
Humidity: 5%~90%
Non-Condensing |
