Ubiquiti UniFi Access Hub
Overview
The Access Hub is a sophisticated, single-door entry mechanism that also
manages connected Access Readers.
The UniFi Access Hub comes with versatile interfaces, including support for
most electric bolts/strikes, magnetic locks, and 12V access accessories such as
motion sensors, push buttons, and alarms. The three Ethernet PoE powered reader
interfaces minimize need for wiring work and offer a convenient way to add a
UniFi G3-Flex surveillance camera for additional security. The seamlessly
integrated UniFi Access solution is managed with UniFi Access application.
Easily manage users, visitors, schedules, and access policies with the with the
intuitive browser-based interface.
Features
- Powered by 802.3bt (PoE++) switch
- Three 802.3af PoE ports for UniFi readers and G3 Flex surveillance
camera
- 12V powered and dry relays compatible with most locks
- Four inputs for motion sensors, request-to-exit devices and door position
switch
- Managed with UniFi Access Application in UDM-Pro
- DIN-rail mounting
Specifications
|
UA-Hub |
|
|
Dimensions |
190
x 126 x 33 mm |
|
(7.48
x 4.96 x 1.29") |
|
Weight |
457
g |
|
(16.12
oz) |
|
Enclosure
Characteristics |
Plastic
Enclosure with Metal Mount Plate |
|
Mounting
Options |
DIN
Rail |
|
Networking
Interface |
(4)
1 Gbps Ethernet |
|
Max.
Power Consumption |
40W |
|
Power
Method |
802.3bt
PoE |
|
Input
Relays |
REX
- Request to Exit |
|
REN
- Request to Enter |
|
REL
- Remote Release |
|
DPS
- Door Position Sensor |
|
Dry
Output Relay |
|
|
Lock |
Rated
30VDC, up to 1A |
|
Aux |
Rated
30VDC, up to 1A |
|
Powered
Output Relay |
|
|
Lock |
12VDC,
up to 1A |
|
Aux |
12VDC,
up to 0.33A |
|
Line |
12VDC,
up to 0.33A |
|
LEDs |
(1)
System, (3) PoE Out, (4) Input |
|
(2)
Output Relays, (1) 12VDC Out |
|
Buttons |
Terminal
Blocks, Reset |
|
Operating
Temperature |
0
to 40 C (32 to 104 F) |
|
Operating
Humidity |
5
- 90% Noncondensing |
|
Certifications |
CE,
FCC,
IC |
