CISCO Barebone System - 2U Rack-mountable
i2 x Processor Support-Intel C620 Chip-3 TB DDR4 SDRAM DDR4-2666/PC4-21300 Maximum RAM Support-24 Total Memory Slots-12Gb/s SAS RAID Supported Contro

Our Price:

$3,997.10

RRP:

~~$10,685.90~~

You Save:

$6,688.80

Qty:

Add To Cart

or quickly purchase this product

Buy Now

Backorder

Part Number:

503113

(?) Brand:

CISCO Web Site

Manuf No:

HX-C240-M5S
HXC240M5S

Shipping Weight:

1 KG (Includes product packaging)
Estimate Shipping

Add to wishlist

Write a Review

Details Files Finance Images & Video

Enter email address to be notified when this item is available again

Join waiting list

All stock codes associated to this product

HXC240M5S, HX-C240-M5S, 4389906

Cisco Barebone System - 2U Rack-mountable - 2 x Processor Support - Intel C620 Chip - 3 TB DDR4 SDRAM DDR4-2666/PC4-21300 Maximum RAM Support - 24 Total Memory Slots - 12Gb/s SAS RAID Supported Controller - Matrox G200e 8 MB Graphic(s) - 10 2.5" Bay(s) - Processor Support (Xeon Platinum, Xeon Gold, Xeon Silver) - 10 Gigabit Ethernet, Gigabit Ethernet - 2 USB 3.0 Port(s) - 3 Year

UCS C240 M5 SFF server extends the capabilities of Cisco's Unified Computing System portfolio in a 2U form factor with the addition of the Intel Xeon Processor Scalable Family, 24 DIMM slots for 2666 MHz DDR4 DIMMs and capacity points up to 128GB, up to 6 PCI Express (PCIe) 3.0 slots, and up to 26 internal SFF drives. The C240 M5 SFF server also includes one dedicated internal slot for a 12G SAS storage controller card.

The C240 M5 server includes a dedicated internal modular LAN on motherboard (mLOM) slot for installation of a Cisco Virtual Interface Card (VIC) or third-party network interface card (NIC), without consuming a PCI slot, in addition to 2 x 10Gbase-T Intel x550 embedded (on the motherboard) LOM ports.

The Cisco UCS C240 M5 server can be used standalone, or as part of the Cisco Unified Computing System, which unifies computing, networking, management, virtualization, and storage access into a single integrated architecture enabling end-to-end server visibility, management, and control in both bare metal and virtualized environments.

Chipset

Chipset Manufacturer	Intel
Chipset Model	C620

Controllers

Controller Type	12Gb/s SAS
RAID Supported	Yes

I/O Expansions

"Number of Internal 2.5"" Bays"	10
Number of Total Expansion Bays	10

Interfaces/Ports

Total Number of USB Ports	2
Number of USB 3.0 Ports	2

Network &Communication

Ethernet Technology	10 Gigabit Ethernet
	Gigabit Ethernet

Power Description

Input Voltage	230 V AC
	120 V AC

General Information

Product Type	Barebone System
Manufacturer Part Number	HX-C240-M5S
Manufacturer Website Address	https://www.cisco.com/c/en_au
Manufacturer	Cisco Systems, Inc
Product Name	UCS C240 M5 Barebone System
Product Series	C240 M5
Brand Name	Cisco

Display &Graphics

Graphics Controller Manufacturer	Matrox
Graphics Controller Model	G200e
Graphics Memory Capacity	8 MB

Memory

Maximum Memory Supported	3 TB
Memory Technology	DDR4 SDRAM
Memory Standard	DDR4-2666/PC4-21300
Number of Total Memory Slots	24

Physical Characteristics

Weight (Approximate)	26.08 kg
Form Factor	Rack-mountable
Rack Height	2U
Height	87.1 mm
Width	481.6 mm
Depth	766.6 mm

Processor

Processor Supported	Xeon Silver
	Xeon Platinum
	Xeon Bronze
	Xeon Gold
64-bit Processing	Yes
Number of Processors Supported	2

No additional files, specification sheets, guides or documentation found for product.

Warranty: 3 year return to base

Full manufacturers warranty details are available at the manufacturers (CISCO) web site.

Unless otherwise specified Techbuy is normally your first point of contact for warranty related returns, further information regarding our warranty policies and consumer guarantees is available on our policies and service & support pages.

To apply for return of a product just go to our returns page.

These terms are in addition to and do not affect any terms, conditions, guarantees and warranties implied by law.
