HARDWARE
FEATURES |
|
Interface |
1x
2.5 Gigabit Ethernet (RJ-45) Port (supports IEEE802.3at
PoE) |
|
Button |
Reset |
|
Power
Supply |
802.3at
PoE |
|
12
V / 1.5 A DC |
|
Power
Consumption |
EU:
18.1 W |
|
US:
19.8 W |
|
Dimensions
( W x D x H ) |
9.6
x 9.6 x 2.5 in (243 x 243 x 64 mm) |
|
Antenna
Type |
Internal
Omni |
|
2.4
GHz: 2x 4 dBi |
|
5
GHz: 4x 5 dBi |
|
Mounting |
Ceiling
/Wall Mounting (Kits included) |
|
WIRELESS
FEATURES |
|
Wireless
Standards |
IEEE
802.11ax/ac/n/g/b/a |
|
Frequency |
2.4
GHz and 5 GHz |
|
Signal
Rate |
5
GHz: Up to 4804 Mbps |
|
2.4
GHz: Up to 574 Mbps |
|
Wireless
Functions |
1024-QAM |
|
4x
Longer OFDM Symbol |
|
OFDMA |
|
Multiple
SSIDs (Up to 16 SSIDs, 8 for each band) |
|
Enable/Disable
Wireless Radio |
|
Automatic
Channel Assignment |
|
Transmit
Power Control (Adjust Transmit Power on dBm) |
|
QoS(WMM) |
|
MU-MIMO |
|
HE160
(160 MHz Bandwidth) |
|
Seamless
Roaming |
|
Omada
Mesh |
|
Band
Steering |
|
Load
Balance |
|
Airtime
Fairness |
|
Beamforming |
|
Rate
Limit |
|
Reboot
Schedule |
|
Wireless
Schedule |
|
Wireless
Statistics based on SSID/AP/Client |
|
Wireless
Security |
Captive
Portal Authentication |
|
Access
Control |
|
Wireless
Mac Address Filtering |
|
Wireless
Isolation Between Clients |
|
SSID
to VLAN Mapping |
|
Rogue
AP Detection |
|
802.1X
Support |
|
WPA-Personal/Enterprise,
WPA2-Personal/Enterprise,
WPA3-Personal/Enterprise |
|
Transmission
Power |
CE: |
|
<20
dBm(2.4 GHz, EIRP) |
|
<23
dBm(5 GHz, , band1 & band2, EIRP) |
|
<30
dBm(5 GHz, , band3, EIRP) |
|
|
FCC: |
|
<25
dBm (2.4 GHz) |
|
<28
dBm (5 GHz) |
|
MANAGEMENT |
|
Omada
App |
Yes |
|
Centralized
Management |
Omada
Hardware Controller (OC300) |
|
Omada
Hardware Controller (OC200) |
|
Omada
Software Controller |
|
Omada
Cloud-Based Controller |
|
Cloud
Access |
Yes
(Through OC300, OC200, Omada Software Controller, or Omada Cloud-Based
Controller) |
|
Email
Alerts |
Yes |
|
LED
ON/OFF Control |
Yes |
|
Management
MAC Access Control |
Yes |
|
SNMP |
v1,
v2c, v3 |
|
System
Logging Local/Remote Syslog |
Local/Remote
Syslog |
|
SSH |
Yes |
|
Web-based
Management |
HTTP/HTTPS |
|
L3
Management |
Yes |
|
Multi-site
Management |
Yes |
|
Management
VLAN |
Yes |
|
OTHERS |
|
Certification |
CE,
FCC, RoHS |
|
Package
Contents |
EAP670 |
|
Power
Adapter |
|
Ceiling/Wall
Mounting Kits |
|
Installation
Guide |
|
System
Requirements |
Microsoft
Windows XP, Vista, Windows 7, Windows 8, Windows10,
Linux |
|
Environment |
Operating
Temperature: 040 (32104
) |
|
Storage
Temperature: -4070 (-40158
) |
|
Operating
Humidity: 1090% RH non-condensing |
|
Storage
Humidity: 590% RH
non-condensing |
