Storage |
---|
Storage drives installed | No |
Installed storage drive type | No |
Supported storage drive types | HDD & SSD |
Number of storage drives supported | 12 |
Maximum supported storage capacity | 108 TB |
RAID support | Yes |
RAID levels | 0, 5, 6, 10, JBOD |
Hot-swap drive bays | Yes |
Supported file systems | BTRFS, Fat, HFS+, NTFS, ext3, ext4 |
Supported storage drive interfaces | Serial ATA, Serial ATA II, Serial ATA III |
Storage drive sizes supported | 2.5,3.5" |
Processor |
---|
Processor manufacturer | AMD |
Processor family | AMD Ryzen |
Processor model | V1500B |
Processor frequency | 2.2 GHz |
Processor cores | 4 |
Number of processors supported | 1 |
Memory |
---|
Internal memory type | DDR4 |
Internal memory | 4 GB |
Maximum RAM supported | 32 GB |
Memory slots | 2 |
Memory form factor | SO-DIMM |
ECC | Yes |
Network |
---|
Link aggregation | Yes |
Ethernet LAN | Yes |
Ethernet LAN data rates | 1000 Mbit/s |
Wake-on-LAN ready | Yes |
Supported network protocols | SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS, iSCSI, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV |
Ports & interfaces |
---|
USB port | Yes |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
Ethernet LAN (RJ-45) ports | 4 |
PCI Express x8 (Gen 3.x) slots | 1 |
Design |
---|
Chassis type | Tower |
Fan diameter 2 | 12 cm |
Product colour | Black |
Cooling type | Active |
Number of fans | 2 fan(s) |
Fan diameter | 12 cm |
Drive bay locking | Yes |
Performance |
---|
Browser supported | Chrome, Firefox, Edge, Internet Explorer, Safari |
Type | NAS |
Device class | Small & Medium Business |
Backup function | Yes |
Backup features | Cloud, iSCSI LUN |
Multilingual support | Yes |
Noise level | 25 dB |
Operating system installed | DiskStation Manager |
Web-based management | Yes |
Access Control List (ACL) | Yes |
Software |
---|
Operating system installed | DiskStation Manager |
Power |
---|
Power consumption (HDD standby) | 32.12 W |
Power supply location | Built-in |
Power supply unit (PSU) capacity | 550 W |
Number of power supply units | 1 |
Power consumption (typical) | 73.11 W |
AC input voltage | 100 - 240 V |
AC input frequency | 50 - 60 Hz |
Weight & dimensions |
---|
Width | 300 mm |
Depth | 340 mm |
Height | 270 mm |
Weight | 9.5 kg |
Technical details |
---|
Sustainability certificates | RoHS |
Harmonized System (HS) code | 84714100 |
Packaging content |
---|
Cables included | AC, LAN (RJ-45) |
Operational conditions |
---|
Operating temperature (T-T) | 0 - 40 °C |
Operating relative humidity (H-H) | 5 - 95% |
Storage temperature (T-T) | -20 - 60 °C |
Storage relative humidity (H-H) | 5 - 95% |
Certificates |
---|
Certification | FCC
CE
BSMI
VCCI
RCM
UKCA
EAC
CCC
KC
UL |
