Storage |
---|
Storage drives installed | No |
Installed storage drive type | No |
Supported storage drive types | SSD |
Number of storage drives supported | 24 |
RAID support | Yes |
RAID levels | 0, 1, 5, 6, 10, F1, JBOD |
Hot-swap drive bays | Yes |
Supported file systems | BTRFS, FAT32, HFS+, NTFS, exFAT, ext3, ext4 |
Supported storage drive interfaces | Serial ATA III |
Storage drive sizes supported | 2.5" |
Total installed system drives capacity | 1000000 GB |
Processor |
---|
Processor manufacturer | Intel |
Processor family | Intel® Xeon® D |
CPU configuration (max) | 1 |
Processor threads | 16 |
Processor cache | 12 MB |
Processor boost frequency | 2.7 GHz |
Conflict-Free processor | Yes |
Processor model | D-1541 |
Processor frequency | 2.1 GHz |
Processor cores | 8 |
Memory |
---|
Internal memory type | DDR4 |
Internal memory | 16 GB |
Maximum RAM supported | 128 GB |
Memory form factor | RDIMM |
ECC | Yes |
Network |
---|
Ethernet LAN data rate supported (max) | 10000 Mbit/s |
Ethernet LAN | Yes |
Ethernet LAN data rates | 10,100,1000,10000 Mbit/s |
iSCSI support | Yes |
Wake-on-LAN ready | Yes |
Supported network protocols | SMB, AFP, NFS, FTP, WebDAV, CalDAV, iSCSI, Telnet, SSH, SNMP, VPN (PPTP, OpenVPN, L2TP) |
Ports & interfaces |
---|
USB port | Yes |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
Ethernet LAN (RJ-45) ports | 7 |
PCI Express x8 (Gen 3.x) slots | 2 |
Serial ports quantity | 1 |
Design |
---|
Chassis type | Rack (2U) |
Product colour | Black |
Cooling type | Active |
Number of fans | 4 fan(s) |
LED indicators | Status |
Performance |
---|
System log | Yes |
Share folder | Yes |
Browser supported | Google Chrome, Firefox, Microsoft Edge, Safari 13 |
Type | Storage server |
Device class | Large Enterprise Business |
Backup function | Yes |
Backup features | Cloud, USB drive |
Multilingual support | Yes |
Number of users | 16000 user(s) |
Operating system installed | DSM |
Operating system version | 7.1 |
Security algorithms | AES |
Access Control List (ACL) | Yes |
Snapshot | Yes |
Software |
---|
Operating system installed | DSM |
Operating system version | 7.1 |
Power |
---|
AC input voltage | 100 - 240 V |
AC input frequency | 50 - 60 Hz |
Weight & dimensions |
---|
Width | 430.5 mm |
Depth | 692 mm |
Height | 88 mm |
Weight | 15 kg |
Technical details |
---|
Sustainability compliance | Yes |
Sustainability certificates | CE, RoHS |
Packaging content |
---|
Quick start guide | Yes |
Cables included | AC |
Power cables quantity | 2 |
Processor special features |
---|
Intel VT-x with Extended Page Tables (EPT) | Yes |
Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
Intel Virtualization Technology (VT-x) | Yes |
Intel TSX-NI version | 1.00 |
Intel TSX-NI | Yes |
Intel Trusted Execution Technology | Yes |
Intel Secure Key Technology version | 1.00 |
Intel Enhanced Halt State | Yes |
Intel 64 | Yes |
Idle States | Yes |
Execute Disable Bit | Yes |
Enhanced Intel SpeedStep Technology | Yes |
Embedded options available | No |
Operational conditions |
---|
Operating temperature (T-T) | 0 - 35 °C |
Operating relative humidity (H-H) | 8 - 80% |
Storage temperature (T-T) | -20 - 60 °C |
Storage relative humidity (H-H) | 5 - 95% |
