| Performance |
|---|
| 2.4 GHz | Yes |
| 5 GHz | Yes |
| Auto MDI/MDI-X | Yes |
| Wi-Fi Multimedia (WMM)/(WME) | Yes |
| Syslog | Yes |
| IGMP snooping | Yes |
| Maximum data transfer rate | 867 Mbit/s |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Spread spectrum method | DSSS,OFDM |
| Frequency band | 2.4 - 2.2484, 5.15 - 5.25, 5.25 - 5.35, 5.47 - 5.725, 5.725 - 5.85 GHz |
| VLAN support | Yes |
| Reset button | Yes |
| Rate limiting | Yes |
| Quality of Service (QoS) support | Yes |
| Networking standards | IEEE 802.11a,IEEE 802.11ac,IEEE 802.11b,IEEE 802.11d,IEEE 802.11e,IEEE 802.11g,IEEE 802.11h,IEEE 802.11i,IEEE 802.11k,IEEE 802.11n,IEEE 802.11r,IEEE 802.11v,IEEE 802.11w,IEEE 802.1x,IEEE 802.3,IEEE 802.3ab,IEEE 802.3u |
| Modulation | 16-QAM,64-QAM,256-QAM,BPSK,QPSK |
| Certification | FCC, CE, IC, UL, EN60601-1-2, WEEE/RoHS |
| MIMO | Yes |
| Band steering | Yes |
| Airtime Fairness (ATF) | Yes |
| Remote Authentication Dial-In User Service (RADIUS) | Yes |
| Features |
|---|
| 2.4 GHz | Yes |
| 5 GHz | Yes |
| Auto MDI/MDI-X | Yes |
| Wi-Fi Multimedia (WMM)/(WME) | Yes |
| Maximum data transfer rate | 867 Mbit/s |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Spread spectrum method | DSSS,OFDM |
| Frequency band | 2.4 - 2.2484, 5.15 - 5.25, 5.25 - 5.35, 5.47 - 5.725, 5.725 - 5.85 GHz |
| VLAN support | Yes |
| Rate limiting | Yes |
| Quality of Service (QoS) support | Yes |
| Networking standards | IEEE 802.11a,IEEE 802.11ac,IEEE 802.11b,IEEE 802.11d,IEEE 802.11e,IEEE 802.11g,IEEE 802.11h,IEEE 802.11i,IEEE 802.11k,IEEE 802.11n,IEEE 802.11r,IEEE 802.11v,IEEE 802.11w,IEEE 802.1x,IEEE 802.3,IEEE 802.3ab,IEEE 802.3u |
| Modulation | 16-QAM,64-QAM,256-QAM,BPSK,QPSK |
| Cabling technology | 10/100/1000Base-T(X) |
| Maximal-Ratio Combining (MRC) | Yes |
| Dynamic Frequency Selection (DFS) | Yes |
| Cyclic Shift Diversity (CSD) | Yes |
| Cyclic Delay Diversity (CDD) | Yes |
| Fast roaming | Yes |
| MIMO | Yes |
| Band steering | Yes |
| Airtime Fairness (ATF) | Yes |
| Maximum data transfer rate (2.4 GHz) | 300 Mbit/s |
| Maximum data transfer rate (5 GHz) | 867 Mbit/s |
| Fit AP mode features | Wireless distribution system (WDS) |
| Security |
|---|
| Number of SSID supported | 16 |
| IGMP snooping | Yes |
| Security algorithms | 802.1x RADIUS,EAP-AKA,EAP-FAST,EAP-GTC,EAP-SIM,EAP-TLS,EAP-TTLS,WPA-PSK,WPA-TKIP,WPA2-AES,WPA2-PSK |
| VPN support | L2TP, L2oGRE, PPPoE |
| MAC address filtering | Yes |
| Access Control List (ACL) | Yes |
| Remote Authentication Dial-In User Service (RADIUS) | Yes |
| Protocols |
|---|
| Management protocols | SNMP v1, v2c, v3 |
| DHCP server | Yes |
| Management features |
|---|
| Syslog | Yes |
| Command-line interface (CLI) | Yes |
| Ports & interfaces |
|---|
| Ethernet LAN (RJ-45) ports | 2 |
| Cabling technology | 10/100/1000Base-T(X) |
| Power |
|---|
| Power consumption (max) | 13 W |
| Power consumption (typical) | 8 W |
| Power over Ethernet (PoE) | No |
| Design |
|---|
| Placement | Wall |
| Reset button | Yes |
| LED indicators | Yes |
| Product colour | White |
| Certification | FCC, CE, IC, UL, EN60601-1-2, WEEE/RoHS |
| Antenna |
|---|
| Antenna type | Internal |
| Polarization | Dual polarization |
| Antenna gain level (max) | 13 dBi |
| Antenna features | Integrated antenna |
| Operational conditions |
|---|
| Operating temperature (T-T) | -30 - 60 °C |
| Software |
|---|
| Access Control List (ACL) | Yes |
| Maximal-Ratio Combining (MRC) | Yes |
| Dynamic Frequency Selection (DFS) | Yes |
| Cyclic Shift Diversity (CSD) | Yes |
| Cyclic Delay Diversity (CDD) | Yes |
| Fast roaming | Yes |
| Weight & dimensions |
|---|
| Width | 204 mm |
| Depth | 65 mm |
| Height | 300 mm |
| Weight | 1.3 kg |
| Other features |
|---|
| Polarization | Dual polarization |
