Performance |
---|
2.4 GHz | Yes |
5 GHz | Yes |
Maximum data transfer rate | 3900 Mbit/s |
Ethernet LAN data rates | 10,100,1000,2500 Mbit/s |
Reset button | Yes |
Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.15.4, IEEE 802.3at, IEEE 802.3az |
Modulation | 256-QAM, 1024-QAM, DSSS, OFDM |
Channels quantity | 87 channels |
MIMO type | Multi User MIMO |
MIMO | Yes |
Features |
---|
2.4 GHz | Yes |
5 GHz | Yes |
Maximum data transfer rate | 3900 Mbit/s |
Ethernet LAN data rates | 10,100,1000,2500 Mbit/s |
Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.15.4, IEEE 802.3at, IEEE 802.3az |
Modulation | 256-QAM, 1024-QAM, DSSS, OFDM |
Channels quantity | 87 channels |
Bluetooth | Yes |
Bluetooth version | 5.2 |
MIMO type | Multi User MIMO |
MIMO | Yes |
Maximum data transfer rate (2.4 GHz) | 287 Mbit/s |
Maximum data transfer rate (5 GHz) | 1200 Mbit/s |
Security |
---|
Number of SSID supported | 24 |
Security algorithms | WPA3 |
Ports & interfaces |
---|
USB connector type | Micro-USB, USB Type-A |
USB 2.0 ports quantity | 1 |
Ethernet LAN (RJ-45) ports | 2 |
Power |
---|
Power consumption (max) | 16.6 W |
Power consumption (typical) | 12.3 W |
Power over Ethernet (PoE) | Yes |
Design |
---|
Placement | Ceiling, Wall |
Reset button | Yes |
LED indicators | Yes |
Product colour | White |
Cable lock slot | Yes |
Cable lock slot type | Kensington |
Antenna |
---|
Antenna type | Internal |
Antennas quantity | 7 |
Antenna direction type | Omni-directional |
Weight & dimensions |
---|
Width | 205 mm |
Depth | 205 mm |
Height | 37 mm |
Weight | 850 g |
Packaging data |
---|
Quick start guide | Yes |
Mounting kit | Yes |
Packaging content |
---|
Quick start guide | Yes |
Mounting kit | Yes |
Operational conditions |
---|
Operating relative humidity (H-H) | 0 - 50% |
Operating temperature (T-T) | -40 - 70 °C |
Storage temperature (T-T) | 0 - 95 °C |
