| Management features |
|---|
| Reset button | Yes |
| Multicast support | Yes |
| Switch layer | L2/L3 |
| Switch type | Managed |
| Quality of Service (QoS) support | Yes |
| Network |
|---|
| IGMP snooping | Yes |
| IGMP entries | 256 |
| IGMP proxy | Yes |
| Networking standards | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ac, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x |
| Number of VLANs | 4000 |
| VLAN support | Yes |
| Port mirroring | Yes |
| Link aggregation | Yes |
| Flow control support | Yes |
| Broadcast storm control | Yes |
| 10G support | Yes |
| Virtual LAN features |
|---|
| Number of VLANs | 4000 |
| VLAN support | Yes |
| Data transmission |
|---|
| Number of VLANs | 4000 |
| Jumbo frames | 9000 |
| MAC address table | 16000 entries |
| Number of static routes | 64 |
| Jumbo frames support | Yes |
| Static route | Yes |
| Forwarding rate | 120 Mpps |
| Throughput | 128 Gbit/s |
| Ports & interfaces |
|---|
| Basic switching RJ-45 Ethernet ports quantity | 16 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Installed SFP modules quantity | 8 |
| Installed SFP+ modules quantity | 4 |
| Security |
|---|
| SSH/SSL support | Yes |
| MAC address filtering | Yes |
| IGMP snooping | Yes |
| Access Control List (ACL) | Yes |
| IGMP entries | 256 |
| IGMP proxy | Yes |
| DHCP features | DHCP client, DHCP relay, DHCP server, DHCP snooping |
| Multicast features |
|---|
| Multicast support | Yes |
| Protocols |
|---|
| Management protocols | SNMP v1/v2/v3 |
| Design |
|---|
| Reset button | Yes |
| Rack mounting | Yes |
| Form factor | 1U |
| Performance |
|---|
| Processor frequency | 800 MHz |
| Internal memory | 512 MB |
| Flash memory | 128 MB |
| Mean time between failures (MTBF) | 202977 h |
| Built-in processor | Yes |
| Power |
|---|
| Power supply included | Yes |
| Power over Ethernet (PoE) |
|---|
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet plus (PoE+) ports quantity | 16 |
| Operational conditions |
|---|
| Operating temperature (T-T) | -10 - 65 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 55 - 95% |
| Weight & dimensions |
|---|
| Width | 440 mm |
| Depth | 350 mm |
| Height | 44 mm |
| Packaging data |
|---|
| Package width | 551 mm |
| Package depth | 485 mm |
| Package height | 128 mm |
