Management features |
---|
Multicast support | Yes |
Switch layer | L2 |
Switch type | Managed |
System event log | Yes |
MIB support | MIB-II |
Ports & interfaces |
---|
Copper ethernet cabling technology | 10BASE-T, 100BASE-TX, 1000BASE-LX, 1000BASE-SX, 1000BASE-T |
Basic switching RJ-45 Ethernet ports quantity | 24 |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Installed SFP+ modules quantity | 4 |
Console port | RJ-45 |
Network |
---|
IGMP snooping | Yes |
Networking standards | IEEE 802.1ab, IEEE 802.1p, IEEE 802.1x, IEEE 802.3af, IEEE 802.3at |
Number of VLANs | 4096 |
Copper ethernet cabling technology | 10BASE-T, 100BASE-TX, 1000BASE-LX, 1000BASE-SX, 1000BASE-T |
VLAN support | Yes |
Port mirroring | Yes |
IP routing | Yes |
Auto MDI/MDI-X | Yes |
10G support | Yes |
Virtual LAN features | Tagged VLAN |
Virtual LAN features |
---|
Number of VLANs | 4096 |
VLAN support | Yes |
Virtual LAN features | Tagged VLAN |
Data transmission |
---|
Number of VLANs | 4096 |
MAC address table | 32000 entries |
Switching capacity | 128 Gbit/s |
Jumbo frames support | Yes |
Security |
---|
Security algorithms | 802.1x RADIUS, HTTPS, SNMP, SSH |
IGMP snooping | Yes |
DHCP features | DHCP client, DHCP relay, DHCP snooping |
Multicast features |
---|
Multicast support | Yes |
Design |
---|
Rack mounting | Yes |
Product colour | Black |
Form factor | 1U |
LED indicators | LAN, PoE |
Certification | FCC Class A, ICES Class A, CE (EMC Class A, LVD, RoHS), C-Tick, VCCI Class A, UL cUL, TUV/GS, CB, Mexico UL DGN notification, WEEE, REACH, BSMI, KCC/MSIP, ANATEL |
Number of fans | 2 fan(s) |
Performance |
---|
Internal memory | 512 MB |
Flash memory | 128 MB |
Mean time between failures (MTBF) | 157763 h |
Harmonized System (HS) code | 85176990 |
Technical details |
---|
Harmonized System (HS) code | 85176990 |
Power |
---|
Power consumption (max) | 500.4 W |
Power supply included | Yes |
AC input voltage | 100 - 240 V |
AC input frequency | 50/60 Hz |
Input current | 7 A |
Power over Ethernet (PoE) |
---|
Power over Ethernet (PoE) | Yes |
Total Power over Ethernet (PoE) budget | 410 W |
Operational conditions |
---|
Operating temperature (T-T) | 0 - 40 °C |
Storage temperature (T-T) | -40 - 70 °C |
Operating relative humidity (H-H) | 10 - 95% |
Heat dissipation | 1706.4 BTU/h |
Weight & dimensions |
---|
Width | 440 mm |
Depth | 44 mm |
Height | 260 mm |
Weight | 3.9 kg |
