Data transmission |
---|
Firewall throughput | 3000 Mbit/s |
VPN throughput | 1300 Mbit/s |
IPS/IDS throughput | 1500 Mbit/s |
Maximum firewall connections per second | 9000 |
Maximum firewall connections | 900000 |
Maximum connections (DPI) | 200000 |
Maximum connections (SPI) | 900000 |
VoIP | Yes |
Load balancing | Yes |
Network |
---|
VPN tunnels quantity | 100 |
Quality of Service (QoS) support | Yes |
DHCP server | Yes |
Static route | Yes |
Security |
---|
Firewall security | Yes |
DDoS protection | Yes |
Deep Packet Inspection (DPI) | Yes |
Stateful Packet Inspection (SPI) | Yes |
Protocols |
---|
Supported network protocols | TCP/IP, UDP, ICMP, HTTP, HTTPS, IPSec, ISAKMP/IKE, SNMP, DHCP, PPPoE, L2TP, PPTP, RADIUS |
Management features |
---|
LED indicators | Yes |
URL filtering | Yes |
Ports & interfaces |
---|
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
Connectivity technology | Wired |
Ethernet LAN (RJ-45) ports | 8 |
Ethernet LAN data rates | 1000 Mbit/s |
Number of console ports | 1 |
Power |
---|
AC input frequency | 50/60 Hz |
Input current | 3 A |
Operational conditions |
---|
Operating temperature (T-T) | 0 - 40 °C |
Operating relative humidity (H-H) | 5 - 95% |
Weight & dimensions |
---|
Width | 35 mm |
Depth | 135 mm |
Height | 190 mm |
