All stock codes associated to this product
MCM110ST2, 2951649, 0803982783820
StarTech.com Transceiver/Media Converter - TAA Compliant - 2 Port(s) - 1 x Network (RJ-45) - 1 x ST - DuplexST Port - Optical Fiber, Twisted Pair - Multi-mode - Fast Ethernet - 10Base-T, 100Base-FX, 100Base-FX - 2 km - AC Adapter - External
The MCM110ST2 10/100 Multi Mode ST Fiber Ethernet Media Converter (2 km) creates a cost-effective Ethernet to fiber link, transparently converting to/from 10Base-T or 100Base-Tx Ethernet signals and 100Base-Fx optical signals to extend an Ethernet network connection over a multimode fiber backbone.The ST media converter supports a maximum multimode fiber optic cable distance of 2km (1.2 miles), providing a simple solution for connecting 10Base-T/100Base-Tx Ethernet networks to remote locations using ST-terminated multimode fiber, while delivering solid network performance and scalability.
Easy to setup and install, this compact, value-conscious fast Ethernet media converter features auto-switching MDI and MDI-X support on the RJ45 UTP connections as well as manual controls for UTP mode, speed, Full and Half Duplex, as well as LFP (Link Fault pass-through) on/off.
Backed by a StarTech.com 2-year warranty and free lifetime technical support.
Miscellaneous
| Additional Information | - Plug Type: M
- Fiber Operating Mode: Half/Full-Duplex
|
| Environmentally Friendly | Yes |
| TAA Compliant | Yes |
Network &Communication
| Network Technology | 100Base-FX |
| 10Base-T |
| Ethernet Technology | Fast Ethernet |
Power Description
| Power Source | AC Adapter |
| Power Consumption | 2.40 W |
| Plug/Connector Type | Type M |
General Information
| Product Type | Transceiver/Media Converter |
| Manufacturer Part Number | MCM110ST2 |
| Manufacturer Website Address | https://www.startech.com/au |
| Manufacturer | StarTech.com |
| Product Name | 10/100 Multi Mode Fiber Copper Fast Ethernet Media Converter ST 2 km |
| Brand Name | StarTech.com |
Interfaces/Ports
| Number of Network (RJ-45) Ports | 1 |
| Network (RJ-45) | Yes |
| Number of ST Ports | 1 |
| Total Number of Ports | 2 |
| ST Port Type | Duplex |
Media &Performance
| Maximum Distance Supported | 2 km |
| Media Type Supported | Twisted Pair |
| Optical Fiber |
| Fiber Mode Supported | Multi-mode |
| Fiber Optic Wavelength | 1310 nm |
Physical Characteristics
| Weight (Approximate) | 82.2 g |
| Form Factor | External |
| Height | 20.3 mm |
| Width | 76.2 mm |
| Depth | 94 mm |
