Performance |
---|
Windows operating systems supported | Windows 10, Windows 7, Windows 8 |
Linux operating systems supported | Kernel 2.6.31, Kernel 2.6.33, Kernel 3.12, Kernel 3.3, Kernel 4.6.4 |
Interface | PCI Express 3.0 |
Component for | PC |
SSD capacity | 512 GB |
Read speed | 1700 MB/s |
Write speed | 900 MB/s |
NVMe | Yes |
NVMe version | 1.3 |
Memory type | 3D NAND |
PCI Express interface data lanes | x4 |
Random read (4KB) | 160000 IOPS |
Random write (4KB) | 140000 IOPS |
S.M.A.R.T. support | Yes |
Hardware encryption | No |
Mean time between failures (MTBF) | 2000000 h |
TBW rating | 200 |
Design |
---|
Certification | FCC, BSMI, KC, RCM |
SSD form factor | M.2 |
System requirements |
---|
Windows operating systems supported | Windows 10, Windows 7, Windows 8 |
Linux operating systems supported | Kernel 2.6.31, Kernel 2.6.33, Kernel 3.12, Kernel 3.3, Kernel 4.6.4 |
Features |
---|
Interface | PCI Express 3.0 |
Component for | PC |
SSD capacity | 512 GB |
Read speed | 1700 MB/s |
Write speed | 900 MB/s |
NVMe | Yes |
NVMe version | 1.3 |
Memory type | 3D NAND |
PCI Express interface data lanes | x4 |
Random read (4KB) | 160000 IOPS |
Random write (4KB) | 140000 IOPS |
S.M.A.R.T. support | Yes |
Hardware encryption | No |
Mean time between failures (MTBF) | 2000000 h |
TBW rating | 200 |
Windows operating systems supported | Windows 10, Windows 7, Windows 8 |
Linux operating systems supported | Kernel 2.6.31, Kernel 2.6.33, Kernel 3.12, Kernel 3.3, Kernel 4.6.4 |
Certification | FCC, BSMI, KC, RCM |
SSD form factor | M.2 |
Harmonized System (HS) code | 84717070 |
Power |
---|
Operating voltage | 3.3 V |
Operational conditions |
---|
Operating temperature (T-T) | 0 - 70 °C |
Maximum operating temperature | 70 °C |
Technical details |
---|
Interface | PCI Express 3.0 |
Operating temperature (T-T) | 0 - 70 °C |
SSD form factor | M.2 |
Harmonized System (HS) code | 84717070 |
Sustainability certificates | CE |
Software |
---|
Windows operating systems supported | Windows 10, Windows 7, Windows 8 |
Linux operating systems supported | Kernel 2.6.31, Kernel 2.6.33, Kernel 3.12, Kernel 3.3, Kernel 4.6.4 |
Weight & dimensions |
---|
Width | 22 mm |
Depth | 80 mm |
Height | 2.23 mm |
Weight | 8 g |
