Performance |
---|
2.4 GHz | Yes |
5 GHz | Yes |
Auto MDI/MDI-X | Yes |
Maximum data transfer rate | 5375 Mbit/s |
Ethernet LAN data rates | 100,1000,2500 Mbit/s |
Spread spectrum method | DSSS, OFDM, OFDMA |
Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3at, IEEE 802.3az |
Modulation | 16-QAM, 64-QAM, 256-QAM, 1024-QAM, BPSK, CCK, QPSK |
MIMO type | Multi User MIMO |
MIMO | Yes |
Features |
---|
2.4 GHz | Yes |
5 GHz | Yes |
Auto MDI/MDI-X | Yes |
Maximum data transfer rate | 5375 Mbit/s |
Ethernet LAN data rates | 100,1000,2500 Mbit/s |
Spread spectrum method | DSSS, OFDM, OFDMA |
Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3at, IEEE 802.3az |
Modulation | 16-QAM, 64-QAM, 256-QAM, 1024-QAM, BPSK, CCK, QPSK |
MIMO type | Multi User MIMO |
MIMO | Yes |
Maximum data transfer rate (2.4 GHz) | 575 Mbit/s |
Maximum data transfer rate (5 GHz) | 4800 Mbit/s |
Security |
---|
Security algorithms | WPA, WPA2, WPA3 |
Ports & interfaces |
---|
USB connector type | USB Type-C |
Ethernet LAN (RJ-45) ports | 2 |
Power |
---|
Power consumption (max) | 32 W |
Power over Ethernet (PoE) | Yes |
Design |
---|
Placement | Pole, Wall |
Product colour | White |
Antenna |
---|
Number of connectors | 6 |
Antenna type | External |
Antenna gain level (max) | 4.2 dBi |
Antenna connector type | N-type |
Antenna features | Integrated antenna |
Operational conditions |
---|
Operating relative humidity (H-H) | 5 - 93% |
Operating temperature (T-T) | -40 - 65 °C |
Storage temperature (T-T) | -40 - 70 °C |
Operating altitude | 0 - 3000 m |
Technical details |
---|
Harmonized System (HS) code | 85176990 |
Weight & dimensions |
---|
Width | 240 mm |
Depth | 240 mm |
Height | 190 mm |
Weight | 2.7 kg |
