Data transmission |
---|
Firewall throughput | 5500 Mbit/s |
SSL inspection throughput | 800 Mbit/s |
IPSec VPN throughput | 2.1 Gbit/s |
Maximum connections (DPI) | 500000 |
HTTPS encryption | Yes |
VoIP | Yes |
Performance |
---|
Heat dissipation | 73.32 BTU/h |
Network |
---|
VPN tunnels quantity | 250 |
Local user database | 250 |
Quality of Service (QoS) support | Yes |
Number of VLANs | 256 |
DHCP server | Yes |
DHCP client | Yes |
Number of LAN Access Points (max) | 32 |
Security |
---|
Security algorithms | 3DES, 128-bit AES, 192-bit AES, 256-bit AES, DES, MD5, SHA-1 |
Protocols |
---|
Supported network protocols | TCP/IP, UDP, ICMP, HTTP, HTTPS, IPSec, ISAKMP/IKE, SNMP, DHCP, PPPoE, L2TP, PPTP, RADIUS, IEEE 802.3 |
Routing protocols | BGP, BGP4, OSPF, RIP, RIP-1, RIP-2 |
Management features |
---|
LED indicators | Yes |
Ports & interfaces |
---|
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
Installed SFP+ modules quantity | 3 |
Connectivity technology | Wired |
Ethernet LAN (RJ-45) ports | 16 |
Ethernet LAN data rates | 1000,10000 Mbit/s |
Console port | RJ-45 |
Remote management port | RJ-45 (Gigabit) |
Number of console ports | 1 |
Storage |
---|
Storage media type | Flash |
Total storage capacity | 256 GB |
Flash memory | 64000 MB |
Design |
---|
Rack mounting | Yes |
Form factor | 1U |
Built-in display | Yes |
Power |
---|
AC input voltage | 100-240 V |
AC input frequency | 50/60 Hz |
Peak power | 60 W |
Power consumption (max) | 21.5 W |
Features |
---|
SSL inspection throughput | 800 Mbit/s |
Operational conditions |
---|
Operating temperature (T-T) | 0 - 40 °C |
Storage temperature (T-T) | -40 - 70 °C |
Operating relative humidity (H-H) | 5 - 95% |
Storage relative humidity (H-H) | 5 - 95% |
Weight & dimensions |
---|
Weight | 4 kg |
Width | 430 mm |
Depth | 325 mm |
Height | 45 mm |
