| Design |
|---|
| LED indicators | LAN, Power, Signal strength, Status |
| Mounting type | DIN-rail/Wall mounting |
| Product colour | Stainless steel |
| International Protection (IP) code | IP30 |
| Enclosure material | Aluminum |
| Features |
|---|
| Antenna type | External |
| Short Message Service (SMS) | Yes |
| Antenna connector type | SMA |
| Antennas quantity | 4 |
| Built-in processor | Yes |
| Processor frequency | 1500 MHz |
| Performance |
|---|
| Built-in processor | Yes |
| Processor frequency | 1500 MHz |
| Internal memory | 256 MB |
| Flash memory | 512 MB |
| Control display unit | No |
| Mounting type | DIN-rail/Wall mounting |
| Product colour | Stainless steel |
| International Protection (IP) code | IP30 |
| Enclosure material | Aluminum |
| Protocols |
|---|
| Supported network protocols | TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, SMTP, SSL v3, TLS, PPP, PPPoE, SSH, DHCP, SNMP, MQTT, Wake on LAN (WOL) |
| Routing protocols | NHRP, BGP, EIGRP, OSPFv2, RIP-1, RIP-2 |
| Network |
|---|
| Dynamic DNS (DDNS) | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Cabling technology | 10/100/1000Base-T(X) |
| Security |
|---|
| VLAN support | Yes |
| DoS attack prevention | Yes |
| MAC address filtering | Yes |
| Firewall security | Yes |
| Network address translation (NAT) | Yes |
| Ports & interfaces |
|---|
| Number of simultaneous SIM cards | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| SIM card type | MiniSIM |
| SIM card slot | Yes |
| Management features |
|---|
| Web-based management | Yes |
| Syslog | Yes |
| Reset button | Yes |
| Power |
|---|
| DC input voltage | 9 - 30 V |
| Power consumption (max) | 6 W |
| Weight & dimensions |
|---|
| Weight | 241 g |
| Width | 100 mm |
| Height | 30 mm |
| Depth | 93.4 mm |
| Packaging content |
|---|
| Cables included | LAN (RJ-45), Micro-USB |
| Quick start guide | Yes |
| AC adapter included | Yes |
| Operational conditions |
|---|
| Operating temperature (T-T) | -40 - 75 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Technical details |
|---|
| Built-in processor | Yes |
| Antenna type | External |
| Short Message Service (SMS) | Yes |
| Quick start guide | Yes |
| Processor frequency | 1500 MHz |
| Number of simultaneous SIM cards | 1 |
| Antenna connector type | SMA |
| AC adapter included | Yes |
| Indication |
|---|
| LED indicators | LAN, Power, Signal strength, Status |
| Memory |
|---|
| Internal memory | 256 MB |
| Flash memory | 512 MB |
| Display |
|---|
| Control display unit | No |
| Antenna |
|---|
| Antenna type | External |
| Antenna connector type | SMA |
| Antennas quantity | 4 |
