Ethernet LAN features |
---|
Ethernet WAN | Yes |
Ethernet LAN interface type | Gigabit Ethernet |
Ethernet LAN | Yes |
Ethernet LAN data rates | 100,1000 Mbit/s |
DSL features |
---|
DSL WAN | No |
Mobile network |
---|
SIM card slot | No |
3G/4G USB modem compatibility | No |
Mobile network generation | Not supported |
Network |
---|
Wake-on-LAN ready | Yes |
Network address translation (NAT) | Yes |
Ethernet LAN interface type | Gigabit Ethernet |
Ethernet LAN | Yes |
Port forwarding | Yes |
Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
Ethernet LAN data rates | 100,1000 Mbit/s |
VPN server | IPSec, OpenVPN |
SSID-based VLAN assignment | Yes |
Load balancing system | Yes |
Dynamic DNS (DDNS) | Yes |
Auto-sensing | Yes |
Maximum Tx power (5 GHz) | 24 dBmW |
Maximum Tx power (2.4 GHz) | 23 dBmW |
Protocols |
---|
DMZ support | Yes |
Performance |
---|
Processor frequency | 800 MHz |
Built-in processor | Yes |
Internal memory | 256 MB |
Weight & dimensions |
---|
Package width | 251.5 mm |
Package weight | 740 g |
Package height | 56 mm |
Package depth | 250 mm |
Width | 145 mm |
Weight | 375 g |
Height | 192 mm |
Depth | 235.5 mm |
Certificates |
---|
Certification | FCC, CE, RCM, IC, UKCA |
Packaging content |
---|
Package type | Box |
Number of products included | 1 pc(s) |
Cables included | LAN (RJ-45) |
AC adapter included | Yes |
Quick installation guide | Yes |
Antenna included | Yes |
WAN connection |
---|
Ethernet WAN | Yes |
DSL WAN | No |
SIM card slot | No |
3G/4G USB modem compatibility | No |
WAN connection type | SFP |
Wireless LAN features |
---|
Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
WLAN data transfer rate (max) | 1270 Mbit/s |
Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
WLAN data transfer rate (first band) | 867 Mbit/s |
WLAN data transfer rate (second band) | 300 Mbit/s |
Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
Ports & interfaces |
---|
USB port | No |
Ethernet LAN (RJ-45) ports | 4 |
Management features |
---|
Web-based management | Yes |
Wake-on-LAN ready | Yes |
Quality of Service (QoS) support | Yes |
Wi-Fi Multimedia (WMM)/(WME) | Yes |
Bandwidth control | Yes |
MU-MIMO technology | Yes |
MIMO | Yes |
Security |
---|
System event log | Yes |
Security algorithms | AES, SSID, TKIP, WPA, WPA2, WPA2-PSK, WPA3 |
Network address translation (NAT) | Yes |
Firewall | Yes |
DoS attack prevention | Yes |
DMZ support | Yes |
Filtering | Yes |
Design |
---|
Product type | Desktop/pole router |
Wall mountable | Yes |
Product colour | White |
Indication light | Yes |
Other features |
---|
Internal memory | 256 MB |
Sustainability |
---|
Sustainability certificates | CE, Federal Communications Commission (FCC), UKCA |
Antenna |
---|
Antenna design | External |
Antenna gain level (max) | 5 dBi |
Antenna type | 2x2 |
Features |
---|
Processor frequency | 800 MHz |
Certification | FCC, CE, RCM, IC, UKCA |
Built-in processor | Yes |
Internal memory | 256 MB |
Power |
---|
Power source type | AC |
Power consumption (typical) | 12 W |
Output voltage | 12 V |
Output current | 1 A |
AC input voltage | 100 - 240 V |
AC input frequency | 50 - 60 Hz |
Operational conditions |
---|
Storage temperature (T-T) | -10 - 60 °C |
Operating temperature (T-T) | 0 - 50 °C |
Operating relative humidity (H-H) | 10 - 90% |
Packaging data |
---|
Package width | 251.5 mm |
Package weight | 740 g |
Package type | Box |
Package height | 56 mm |
Package depth | 250 mm |
Cables included | LAN (RJ-45) |
AC adapter included | Yes |
Quick installation guide | Yes |
Number of products included | 1 pc(s) |
Antenna included | Yes |
Technical details |
---|
Sustainability certificates | CE, Federal Communications Commission (FCC), UKCA |
