Performance |
---|
Stackable | No |
Management features |
---|
Switch layer | L2 |
Switch type | Managed |
Ports & interfaces |
---|
SFP+ module slots quantity | 4 |
Basic switching RJ-45 Ethernet ports quantity | 24 |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Network |
---|
Over-the-air bluetooth access | Yes |
Data transmission |
---|
Switching capacity | 128 Gbit/s |
Forwarding rate | 95.23 Mpps |
Throughput | 64 Gbit/s |
Design |
---|
Rack mounting | Yes |
Stackable | No |
Display type | LCM |
Product colour | White |
LED indicators | Activity, Link, PoE, Speed |
Housing material | Acrylonitrile butadiene styrene (ABS), Polycarbonate (PC), Steel |
Certification | IC |
Technical details |
---|
Sustainability compliance | Yes |
Sustainability certificates | CE, Federal Communications Commission (FCC) |
Power |
---|
Power supply included | Yes |
AC input voltage | 100 - 240 V |
AC input frequency | 50 - 60 Hz |
DC input voltage | 18 - 27 V |
Power source | AC/DC |
Power over Ethernet (PoE) |
---|
Power over Ethernet (PoE) power per port | 30 W |
Power over Ethernet (PoE) | Yes |
Total Power over Ethernet (PoE) budget | 220 W |
Power over Ethernet (PoE) voltage | 27 V |
Power over Ethernet (PoE) type supported | Passive PoE |
Operational conditions |
---|
Operating temperature (T-T) | -10 - 50 °C |
Operating relative humidity (H-H) | 5 - 95% |
Weight & dimensions |
---|
Width | 442.4 mm |
Depth | 267.5 mm |
Height | 43.7 mm |
Weight | 4 kg |
Packaging data |
---|
Manual | Yes |
Sustainability |
---|
Sustainability compliance | Yes |
Sustainability certificates | CE, Federal Communications Commission (FCC) |
Packaging content |
---|
Manual | Yes |
