| Management features |
|---|
| Multicast support | Yes |
| ARP inspection | Yes |
| Switch layer | L3 |
| Switch type | Managed |
| Web-based management | Yes |
| System event log | Yes |
| Quality of Service (QoS) support | Yes |
| Network |
|---|
| IGMP snooping | Yes |
| Networking standards | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1w, IEEE 802.3ad |
| Full duplex | Yes |
| Number of VLANs | 4094 |
| VLAN support | Yes |
| Spanning tree protocol | Yes |
| Port mirroring | Yes |
| Link aggregation | Yes |
| Flow control support | Yes |
| Broadcast storm control | Yes |
| Auto MDI/MDI-X | Yes |
| 10G support | Yes |
| Auto-negotiation | Yes |
| Policy-based routing | Yes |
| Virtual LAN features |
|---|
| Number of VLANs | 4094 |
| VLAN support | Yes |
| Data transmission |
|---|
| Number of VLANs | 4094 |
| Jumbo frames | 9600 |
| MAC address table | 512000 entries |
| Switching capacity | 272 Gbit/s |
| Jumbo frames support | Yes |
| Forwarding rate | 202.38 Mpps |
| Performance |
|---|
| Stackable | Yes |
| Auto-negotiation | Yes |
| Firmware upgradeable | Yes |
| Mean time between failures (MTBF) | 321515 h |
| Harmonized System (HS) code | 85176990 |
| Ports & interfaces |
|---|
| SFP+ module slots quantity | 4 |
| Basic switching RJ-45 Ethernet ports quantity | 16 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Gigabit Ethernet (copper) ports quantity | 24 |
| Security |
|---|
| Authentication | Port-based authentication |
| Security algorithms | 802.1x RADIUS |
| IGMP snooping | Yes |
| Whitelist | Yes |
| Persistent MAC Learning (Sticky MAC) | Yes |
| Authentication type | RADIUS |
| DHCP features | DHCP server, DHCP snooping |
| Multicast features |
|---|
| Multicast support | Yes |
| Protocols |
|---|
| Switching protocols | DSCP-to-CoS, RSTP, STP, CDP, LLDP |
| Routing protocols | CDP |
| Design |
|---|
| Rack mounting | Yes |
| Stackable | Yes |
| Product colour | White |
| Form factor | 1U |
| Certification | CSA-US, FCC, IC, CE, RCM, RoHS |
| Technical details |
|---|
| Harmonized System (HS) code | 85176990 |
| Power |
|---|
| Power consumption (max) | 867 W |
| Power supply included | Yes |
| AC input voltage | 100 - 240 V |
| AC input frequency | 47/63 Hz |
| Power consumption (typical) | 215 W |
| Power over Ethernet (PoE) |
|---|
| Power over Ethernet (PoE) power per port | 60 W |
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet (PoE) ports quantity | 24 |
| Operational conditions |
|---|
| Operating temperature (T-T) | -5 - 50 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Weight & dimensions |
|---|
| Width | 484.6 mm |
| Depth | 594.7 mm |
| Height | 44.4 mm |
| Weight | 6.6 kg |
| Logistics data |
|---|
| Harmonized System (HS) code | 85176990 |
