Ports & interfaces |
---|
Copper ethernet cabling technology | 10BASE-T, 100BASE-T, 1000BASE-TX |
SFP module slots quantity | 16 |
Basic switching RJ-45 Ethernet ports quantity | 12 |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Console port | RJ-45 |
Gigabit Ethernet (copper) ports quantity | 12 |
Compatible memory cards | SD |
Network |
---|
IGMP snooping | Yes |
Networking standards | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
Full duplex | Yes |
Number of VLANs | 1005 |
Copper ethernet cabling technology | 10BASE-T, 100BASE-T, 1000BASE-TX |
VLAN support | Yes |
Spanning tree protocol | Yes |
Link aggregation | Yes |
Broadcast storm control | Yes |
10G support | No |
Virtual LAN features | Private VLAN, Port-based VLAN |
Virtual LAN features |
---|
Number of VLANs | 1005 |
VLAN support | Yes |
Virtual LAN features | Private VLAN, Port-based VLAN |
Data transmission |
---|
Number of VLANs | 1005 |
MAC address table | 16000 entries |
Switching capacity | 56 Gbit/s |
Number of queues | 4 |
Static route | Yes |
Forwarding rate | 41.67 Mpps |
Management features |
---|
ARP inspection | Yes |
Switch layer | L2/L3 |
Switch type | Managed |
Quality of Service (QoS) support | Yes |
Security |
---|
SSH/SSL support | Yes |
Security algorithms | SNMPv3, SSH |
MAC address filtering | No |
IGMP snooping | Yes |
DHCP features | DHCP server, DHCP snooping, DHCP relay |
Design |
---|
Rack mounting | Yes |
Product colour | Black |
Form factor | 1U |
LED indicators | Yes |
Safety | UL/CSA 60950-1, EN 60950-1 |
Electromagnetic compatibility | FCC 47 CFR Part 15 Class A, EN 55022A Class A, VCCI Class A |
Certification | CE, RoHS, TAA |
Performance |
---|
Flash memory | 256 MB |
Mean time between failures (MTBF) | 390190 h |
Harmonized System (HS) code | 85176990 |
Technical details |
---|
Harmonized System (HS) code | 85176990 |
Power |
---|
Power consumption (max) | 90 W |
Surge protection | Yes |
Power over Ethernet (PoE) |
---|
Power over Ethernet (PoE) | Yes |
Power over Ethernet (PoE) ports quantity | 12 |
Power over Ethernet plus (PoE+) ports quantity | 12 |
Operational conditions |
---|
Operating temperature (T-T) | -40 - 75 °C |
Storage temperature (T-T) | -40 - 85 °C |
Operating relative humidity (H-H) | 0 - 95% |
Storage relative humidity (H-H) | 0 - 95% |
Operating altitude | 0 - 4206 m |
Non-operating altitude | 0 - 4572 m |
Weight & dimensions |
---|
Width | 445 mm |
Depth | 356 mm |
Height | 44.5 mm |
