Performance |
---|
2.4 GHz | Yes |
5 GHz | Yes |
Wi-Fi Multimedia (WMM)/(WME) | Yes |
Maximum data transfer rate | 5200 Mbit/s |
Ethernet LAN data rates | 10,100,1000 Mbit/s |
Wi-Fi data rate (max) | 2600 Mbit/s |
Frequency band | 2.412 - 5.825 GHz |
Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3at, IEEE 802.3u |
Channels quantity | 11 channels |
Certification | UL 60950-1
CAN/CSA-C22.2 No. 60950-1
UL 2043
IEC 60950-1
EN 60950-1
EN 50155
FCC Part 15.107, 15.109, 15.247, 15.407, 14-30
RSS-247
EN 300.328, EN 301.893
ARIB-STD 66
ARIB-STD T71
ICES-003
VCCI
EN 301.489-1 / -17
EN 60601-1-2 |
Remote Authentication Dial-In User Service (RADIUS) | Yes |
Internal memory | 1024 MB |
Flash memory | 256 MB |
Features |
---|
2.4 GHz | Yes |
5 GHz | Yes |
Wi-Fi Multimedia (WMM)/(WME) | Yes |
Maximum data transfer rate | 5200 Mbit/s |
Ethernet LAN data rates | 10,100,1000 Mbit/s |
Wi-Fi data rate (max) | 2600 Mbit/s |
Frequency band | 2.412 - 5.825 GHz |
Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3at, IEEE 802.3u |
Channels quantity | 11 channels |
Internal memory | 1024 MB |
Flash memory | 256 MB |
Security |
---|
Security algorithms | 802.1x RADIUS, EAP-FAST, EAP-PEAP, EAP-SIM, EAP-TLS, EAP-TTLS, MSCHAPv2, PEAP, WPA, WPA2 |
Remote Authentication Dial-In User Service (RADIUS) | Yes |
Ports & interfaces |
---|
Ethernet LAN (RJ-45) ports | 2 |
Power |
---|
Power over Ethernet (PoE) | Yes |
Design |
---|
Placement | Ceiling |
Internal | No |
LED indicators | Yes |
Product colour | White |
Certification | UL 60950-1
CAN/CSA-C22.2 No. 60950-1
UL 2043
IEC 60950-1
EN 60950-1
EN 50155
FCC Part 15.107, 15.109, 15.247, 15.407, 14-30
RSS-247
EN 300.328, EN 301.893
ARIB-STD 66
ARIB-STD T71
ICES-003
VCCI
EN 301.489-1 / -17
EN 60601-1-2 |
Antenna |
---|
Number of connectors | 4 |
Antenna gain level (max) | 6 dBi |
Antenna features | Detachable antenna |
Weight & dimensions |
---|
Width | 220 mm |
Depth | 222.8 mm |
Height | 63.5 mm |
Weight | 2.09 kg |
Operational conditions |
---|
Operating relative humidity (H-H) | 10 - 90% |
Operating temperature (T-T) | -20 - 50 °C |
Storage temperature (T-T) | -30 - 70 °C |
Operating altitude | 0 - 3000 m |
Non-operating altitude | 0 - 4572 m |
