Performance |
---|
2.4 GHz | Yes |
5 GHz | Yes |
Wi-Fi Multimedia (WMM)/(WME) | Yes |
Maximum data transfer rate | 1000 Mbit/s |
Ethernet LAN data rates | 10,100,1000 Mbit/s |
Frequency band | 2.412 - 2.462, 5.18 - 5.32, 5.5 - 5.7 (excludes 5.6 - 5.64), 5.745 - 5.825 |
Number of users | 400 user(s) |
VLAN support | Yes |
Transmitting power | 20 dBmW |
Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11d, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i, IEEE 802.11n, IEEE 802.11r, IEEE 802.1x |
Channels quantity | 32 channels |
Channel bandwidth | 80 MHz |
Certification | UL 60950-1, CAN/CSA-C22.2 No. 60950-1, UL 2043, IEC 60950-1, EN 60950-1, FCC Part 15.247, 15.407, RSS-247 (Canada), EN 300.328, EN 301.893 (Europe), ARIB-STD 66 (Japan), ARIB-STD T71 (Japan), EMI and susceptibility (Class B), FCC Part 15.107 and 15.109, ICES-003 (Canada), VCCI (Japan), EN 301.489-1 and -17 (Europe), EN 50385 |
MIMO type | Multi User MIMO |
MIMO | Yes |
Internal memory | 1024 MB |
Flash memory | 256 MB |
Built-in processor | Yes |
Processor frequency | 710 MHz |
Features |
---|
2.4 GHz | Yes |
5 GHz | Yes |
Wi-Fi Multimedia (WMM)/(WME) | Yes |
Maximum data transfer rate | 1000 Mbit/s |
Ethernet LAN data rates | 10,100,1000 Mbit/s |
Frequency band | 2.412 - 2.462, 5.18 - 5.32, 5.5 - 5.7 (excludes 5.6 - 5.64), 5.745 - 5.825 |
Number of users | 400 user(s) |
VLAN support | Yes |
Transmitting power | 20 dBmW |
Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11d, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i, IEEE 802.11n, IEEE 802.11r, IEEE 802.1x |
Channels quantity | 32 channels |
Channel bandwidth | 80 MHz |
Maximal-Ratio Combining (MRC) | Yes |
Dynamic Frequency Selection (DFS) | Yes |
Data unit aggregation | A-MSDU, A-MPDU |
Cyclic Shift Diversity (CSD) | Yes |
MIMO type | Multi User MIMO |
MIMO | Yes |
Maximum data transfer rate (5 GHz) | 867 Mbit/s |
Internal memory | 1024 MB |
Flash memory | 256 MB |
Built-in processor | Yes |
Processor frequency | 710 MHz |
Security |
---|
Security algorithms | 802.1x RADIUS, AES, EAP-FAST, EAP-PEAP, EAP-SIM, EAP-TLS, EAP-TTLS, MSCHAPv2, WPA, WPA2 |
MAC address filtering | Yes |
Ports & interfaces |
---|
WAN connection | Ethernet (RJ-45) |
Ethernet LAN (RJ-45) ports | 1 |
Power |
---|
Power consumption (max) | 8.3 W |
Power over Ethernet (PoE) | Yes |
Design |
---|
Placement | Ceiling, Wall |
LED indicators | Yes |
Product colour | White |
Certification | UL 60950-1, CAN/CSA-C22.2 No. 60950-1, UL 2043, IEC 60950-1, EN 60950-1, FCC Part 15.247, 15.407, RSS-247 (Canada), EN 300.328, EN 301.893 (Europe), ARIB-STD 66 (Japan), ARIB-STD T71 (Japan), EMI and susceptibility (Class B), FCC Part 15.107 and 15.109, ICES-003 (Canada), VCCI (Japan), EN 301.489-1 and -17 (Europe), EN 50385 |
Antenna |
---|
Antenna type | Internal |
Antenna gain level (max) | 4 dBi |
Software |
---|
Maximal-Ratio Combining (MRC) | Yes |
Dynamic Frequency Selection (DFS) | Yes |
Data unit aggregation | A-MSDU, A-MPDU |
Cyclic Shift Diversity (CSD) | Yes |
Weight & dimensions |
---|
Width | 150.8 mm |
Depth | 150.8 mm |
Height | 33 mm |
Weight | 400 g |
Packaging data |
---|
Number of products included | 1 pc(s) |
Packaging content |
---|
Number of products included | 1 pc(s) |
Operational conditions |
---|
Operating relative humidity (H-H) | 10 - 90% |
Operating temperature (T-T) | 0 - 40 °C |
Storage temperature (T-T) | -30 - 70 °C |
Storage relative humidity (H-H) | 10 - 90% |
Operating altitude | 0 - 3000 m |
Non-operating altitude | 0 - 4572 m |
