| Performance |
|---|
| 2.4 GHz | Yes |
| 5 GHz | Yes |
| Maximum data transfer rate | 1300 Mbit/s |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Frequency band | 2.412 - 2.462, 5.745 - 5.825 GHz |
| Web-based management | Yes |
| Transmitting power | 27 dBmW |
| Reset button | Yes |
| Networking standards | IEEE 802.11ac,IEEE 802.11g,IEEE 802.11i,IEEE 802.11n,IEEE 802.1x,IEEE 802.3at |
| Channels quantity | 16 channels |
| Channel bandwidth | 80 MHz |
| Certification | UL60950, 2 nd Edition, CAN/CSA-C22.2 No. 60950, 2 nd Edition, IEC 60950, 2 nd Edition, EN 60950, 2 nd Edition, ANSI/IEEE C62.41, EN61000-4-5 Lev el 4 AC Surge Immunity, EN61000-4-4 Lev el 4 Electrical Fast Transient Burst Immunity, EN61000-4-3 Lev el 4 EMC Field Immunity, EN61000-4-2 Lev el 2 ESD Immunity, EN60950 Overvoltage Category IV, FCC Part 15.247, 15.407, FCC Bulletin OET-65C, RSS-247, RSS-102, AS/NZS 4268.2003, ARIB-STD 66 (Japan), ARIB-STD T71 (Japan), EN 300 328, EN 301 893, FCC part 15.107, 15.109, ICES-003, EN 301 489-1, -17 |
| MIMO type | Multi User MIMO |
| MIMO | Yes |
| Features |
|---|
| 2.4 GHz | Yes |
| 5 GHz | Yes |
| Maximum data transfer rate | 1300 Mbit/s |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Frequency band | 2.412 - 2.462, 5.745 - 5.825 GHz |
| Transmitting power | 27 dBmW |
| Networking standards | IEEE 802.11ac,IEEE 802.11g,IEEE 802.11i,IEEE 802.11n,IEEE 802.1x,IEEE 802.3at |
| Channels quantity | 16 channels |
| Channel bandwidth | 80 MHz |
| Maximal-Ratio Combining (MRC) | Yes |
| Dynamic Frequency Selection (DFS) | Yes |
| Data unit aggregation | A-MSDU, A-MPDU |
| Cyclic Shift Diversity (CSD) | Yes |
| MIMO type | Multi User MIMO |
| MIMO | Yes |
| Security |
|---|
| Security algorithms | AES,EAP-PEAP,EAP-SIM,EAP-TLS,EAP-TTLS,LEAP,WPA,WPA2 |
| MAC address filtering | Yes |
| Management features |
|---|
| Web-based management | Yes |
| Ports & interfaces |
|---|
| WAN connection | Ethernet (RJ-45) |
| Ethernet LAN (RJ-45) ports | 1 |
| DC-in jack | Yes |
| Power |
|---|
| Power consumption (typical) | 25 W |
| Power over Ethernet (PoE) | Yes |
| Design |
|---|
| Placement | Pole, Wall |
| International Protection (IP) code | IP67 |
| Reset button | Yes |
| LED indicators | Yes |
| Product colour | Grey |
| Certification | UL60950, 2 nd Edition, CAN/CSA-C22.2 No. 60950, 2 nd Edition, IEC 60950, 2 nd Edition, EN 60950, 2 nd Edition, ANSI/IEEE C62.41, EN61000-4-5 Lev el 4 AC Surge Immunity, EN61000-4-4 Lev el 4 Electrical Fast Transient Burst Immunity, EN61000-4-3 Lev el 4 EMC Field Immunity, EN61000-4-2 Lev el 2 ESD Immunity, EN60950 Overvoltage Category IV, FCC Part 15.247, 15.407, FCC Bulletin OET-65C, RSS-247, RSS-102, AS/NZS 4268.2003, ARIB-STD 66 (Japan), ARIB-STD T71 (Japan), EN 300 328, EN 301 893, FCC part 15.107, 15.109, ICES-003, EN 301 489-1, -17 |
| Antenna |
|---|
| Number of connectors | 4 |
| Antenna type | External |
| Antenna connector type | N-type |
| Antenna features | Detachable antenna |
| Operational conditions |
|---|
| Operating temperature (T-T) | -40 - 65 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Storage relative humidity (H-H) | 5 - 95% |
| Software |
|---|
| Maximal-Ratio Combining (MRC) | Yes |
| Dynamic Frequency Selection (DFS) | Yes |
| Data unit aggregation | A-MSDU, A-MPDU |
| Cyclic Shift Diversity (CSD) | Yes |
| Weight & dimensions |
|---|
| Width | 229 mm |
| Depth | 171 mm |
| Height | 98 mm |
| Weight | 2.5 kg |
| Packaging data |
|---|
| Number of products included | 1 pc(s) |
| Packaging content |
|---|
| Number of products included | 1 pc(s) |
